Solenoid actuated flange valve, 50 mm nominal diameter, 2/2 NC, 24 V DC, cast steel - Norgren 8303714.9151.02400

With a body of cast steel and seals of Ethylene propylene diene monomer (EPDM) Norgren 8303714.9151.02400 switches gases and liquids in the range 0.1 to 16 bar.

Benefits

• High flow rate with damped operation
• Operating pressure 0.1 to 16 bar in function 2/2 NC
• Kv value 41 m³/h and Cv value 47.4 gpm
• Seal material Ethylene propylene diene monomer (EPDM) for fluid temperatures of -10 to 90 °C
• Protection class IP65 at an ambient temperature of -10 to 50 °C

Applications

The valve is used in water treatment, in cleaning and dosing plants and in machine building wherever gases and liquids have to be switched at 0.1 to 16 bar.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The electrical connection follows DIN EN 175301-803 form A. The housing reaches protection class IP65.
