Solenoid actuated flange valve, 25 mm nominal diameter, 2/2 NC, 230 V AC, cast steel - Norgren 8303400.9111.23050

Norgren 8303400.9111.23050 is a solenoid actuated flange valve in function 2/2 NC and switches gases and liquids at an operating pressure of 0.1 to 16 bar.

Benefits

• High flow rate
• Damped operation
• Compact and functional design
• Operating pressure 0.1 to 16 bar in function 2/2 NC
• Kv value 9.5 m³/h and Cv value 11 gpm
• Seal material Nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C

Applications

The valve is used in water treatment, in cleaning and dosing plants and in machine building wherever gases and liquids have to be switched at 0.1 to 16 bar.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The electrical connection follows DIN EN 175301-803 form A. The housing reaches protection class IP65.
