2/2 way diaphragm valve, solenoid operated, NC, G3/8, 230 V AC 50 Hz, 15/12 VA, NBR, brass - Norgren 8240100.9101.23050
The 2/2 way diaphragm valve with NBR seals switches directly on 230 V AC from the controller. Norgren 8240100.9101.23050 is a 2/2 way diaphragm valve with G3/8 port, for 230 V AC and rated for 0.1 to 16 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 2/2 way diaphragm valve 8240100.9101.23050 has a G3/8 port, is designed for 230 V AC and operates from 0.1 to 16 bar. The 2/2 way diaphragm valve reaches a Kv value of 3 m³/h.
Benefits
- Operating pressure 0.1 to 16 bar
- Flow 50 l/min for fast filling and exhausting
- Kv value 3 m³/h as the sizing figure for the line
- Nominal diameter 10 mm
- Electrical connection DIN EN 175301-803 form A for common connectors
- Power consumption 15/12 VA at the coil
Applications
The valve from the 82400 series is installed in lines that switch gases and liquids.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8240100.9101.23050 |
| Product type | 2/2 way diaphragm valve |
| Series | 82400 |
| Valve function | 2/2 |
| Normal position | Normally closed (NC) |
| Actuation | solenoid pilot / spring return |
| Port size | G3/8 |
| Nominal diameter | 10 mm |
| Operating pressure | 0.1 to 16 bar |
| Flow | 50 l/min |
| Kv value | 3 m³/h |
| Medium | gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | brass |
| Seal material | nitrile rubber (NBR) |
| Valve technology | diaphragm |
| Voltage | 230 V AC, 50 Hz |
| Power consumption | 15/12 VA |
| Coil code | 9101 |
| Electrical connection | DIN EN 175301-803 form A |
| Protection class | IP65 |
| Dimensions L x W x H | 78.5 x 60 x 44 mm |
| Standards | DIN EN 175301-803, DIN EN 60730-2-8 |
| RoHS | compliant |
| Weight | 0.47 kg |
| Hersteller-Nr | 8240100.9101.23050 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Nominal size DN [mm] | 10 |
| Housing material | Brass |
| Function | 2/2 closed monostable |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803, DIN EN 60730-2-8 |
| Operating voltage | 230 V AC |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G3/8 |
| Protection rating | IP65 |
| Temperaturbereich | -10-50 °C |
