2/2 way diaphragm valve, solenoid operated, NC, G3/8, without solenoid coil, NBR, brass - Norgren 8240100.9100.00000
Reaches a Kv value of 3 m³/h. Norgren 8240100.9100.00000 is a 2/2 way diaphragm valve with G3/8 port and rated for 0.1 to 16 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 2/2 way diaphragm valve 8240100.9100.00000 has a G3/8 port and operates from 0.1 to 16 bar. The valve from the 82400 series is supplied without solenoid coil, so the coil can be chosen to suit the control voltage.
Benefits
- Operating pressure 0.1 to 16 bar
- Flow 50 l/min for fast filling and exhausting
- Kv value 3 m³/h as the sizing figure for the line
- Nominal diameter 10 mm
- Fluid temperature -10 to 90 °C with NBR seals
- Ambient temperature -10 to 50 °C
Applications
The valve from the 82400 series handles shutting off and releasing gases and liquids.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8240100.9100.00000 |
| Product type | 2/2 way diaphragm valve |
| Series | 82400 |
| Valve function | 2/2 |
| Normal position | Normally closed (NC) |
| Actuation | solenoid pilot / spring return |
| Port size | G3/8 |
| Nominal diameter | 10 mm |
| Operating pressure | 0.1 to 16 bar |
| Flow | 50 l/min |
| Kv value | 3 m³/h |
| Medium | gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | brass |
| Seal material | nitrile rubber (NBR) |
| Valve technology | diaphragm |
| Coil code | 9100 |
| Scope of delivery | without solenoid coil |
| Protection class | IP65 |
| Dimensions L x W x H | 50 x 60 x 70 mm |
| Standards | DIN EN 60730-2-8 |
| RoHS | compliant |
| Weight | 0.3 kg |
| Hersteller-Nr | 8240100.9100.00000 |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Nominal size DN [mm] | 10 |
| Housing material | Brass |
| Function | 2/2 closed monostable |
| Actuation type | Electrical |
| Norm | DIN EN 60730-2-8 |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G3/8 |
| Protection rating | IP65 |
| Temperaturbereich | -10-50 °C |
