Servo-assisted 2/2-way diaphragm valve NC, G3/4, DN 20, 24 V DC, FPM - Norgren 8240303.9169.02400
The Norgren servo-assisted diaphragm valve 8240303.9169.02400 switches gases and liquids at port G3/4 from 0.1 to 16 bar and reaches a Kv value of 6.1 m³/h. At port G3/4 the coil 9169 runs on 24 V DC, and FPM seals are rated for -5 to 110 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a Kv value of 6.1 m³/h and a nominal diameter of 20 mm the Norgren servo-assisted diaphragm valve 8240303.9169.02400 controls lines with port G3/4, normally closed. Via the solenoid pilot the 8240303.9169.02400 opens from 0.1 bar, a spring handles the return.
Operating benefits
- Flow 101 l/min at Kv 6.1 m³/h and nominal diameter 20 mm
- Operating pressure 0.1 to 16 bar, servo assistance from 0.1 bar
- Seal material fluoroelastomer (FPM) for fluid temperatures of -5 to 110 °C
- Solenoid coil 9169 for 24 V DC, power consumption 2 W, tool-free exchange via click-on
- Damped switching in a compact brass body, protection class IP65
Applications
Typical locations for the valve 8240303.9169.02400 are water treatment, cleaning and dosing systems and machine building where gases and liquids at temperatures of -5 to 110 °C have to be switched.
Standards and conformity
Documented for the Norgren 8240303.9169.02400: plug connection to DIN EN 175301-803 form A, suitability as a water valve to DIN EN 60730-2-8, protection class IP65 and RoHS compliance. Under REACH the valve 8240303.9169.02400 contains no SVHC substances and falls under the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8240303.9169.02400 |
| Series | 82400 |
| Design | Diaphragm valve, servo-assisted (indirectly solenoid operated) |
| Valve function | 2/2 NC (normally closed) |
| Actuation | Solenoid pilot, spring return |
| Port size | G3/4 |
| Nominal diameter | 20 mm |
| Operating pressure | 0.1 to 16 bar |
| Flow | 101 l/min |
| Kv value | 6.1 m³/h |
| Cv value | 7.1 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -5 to 110 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Fluoroelastomer (FPM) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 24 V DC |
| Power consumption | 2 W |
| Coil code | 9169 |
| Protection class | IP65 |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | no SVHC substances |
| WEEE | subject to WEEE |
| Hersteller-Nr | 8240303.9169.02400 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 3/4 |
| Nominal size DN [mm] | 20 |
| Housing material | Brass |
| Function | 2/2 closed monostable |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803, DIN EN 60730-2-8 |
| Betriebsdruck max [bar] | 16 |
| Protection rating | IP65 |
| Temperature (max.) | 110 |
