Diaphragm solenoid valve 2/2 NC, G 3/4, DN 20, 24 V DC, 82400 series - Norgren 8240303.9168.02400
The Norgren 8240303.9168.02400 switches gases and liquids through G 3/4 ports with DN 20 nominal size across 0.1 to 16 bar. The 9168 coil of the 8240303.9168.02400 runs on 24 V DC at 2 W, protection class IP00.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With Kv 6.1 m³/h at DN 20 and G 3/4 ports, the Norgren 8240303.9168.02400 switches gases and liquids across 0.1 to 16 bar. The 8240303.9168.02400 uses coil 9168 for 24 V DC at 2 W with protection class IP00. A brass body and FPM seals define the media compatibility of the 8240303.9168.02400.
Benefits
- Kv value 6.1 m³/h, Cv value 7.1 gpm at DN 20 nominal size
- Operating pressure 0.1 to 16 bar for gases and liquids
- Brass body, FPM seals
- Fluid temperature -5 to 110 °C, ambient temperature -10 to 50 °C
- Coil 9168 for 24 V DC, 2 W, protection class IP00
Applications
The 8240303.9168.02400 suits gases and liquids compatible with FPM, at fluid temperatures of -5 to 110 °C.
Standards and compliance
The 8240303.9168.02400 uses a DIN EN 175301-803 form A electrical connection. DIN EN 60730-2-8 is specified as standard for the 8240303.9168.02400. The 8240303.9168.02400 is RoHS compliant, contains no SVHC substances under REACH and is covered by the WEEE directive.
Technical data
| Product type | Diaphragm solenoid valve |
|---|---|
| Series | 82400 |
| Valve function | 2/2 |
| Function | NC (normally closed) |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | G 3/4 |
| Nominal diameter | 20 mm |
| Operating pressure | 0.1 to 16 bar |
| Flow | 101 l/min |
| Kv value | 6.1 m³/h |
| Cv flow coefficient | 7.1 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -5 to 110 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Fluorocarbon rubber (FPM) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 24 V DC |
| Power consumption | 2 W |
| Coil code | 9168 |
| Protection class | IP00 |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer part number | 8240303.9168.02400 |
| Manufacturer | Norgren |
| Hersteller-Nr | 8240303.9168.02400 |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 3/4 |
| Nominal size DN [mm] | 20 |
| Housing material | Brass |
| Design | diaphragm valve |
| Actuation type | Electrical |
| Medientemperatur [°C] | -5 bis 110 |
| Norm | DIN EN 175301-803, DIN EN 60730-2-8 |
| Betriebsdruck max [bar] | 16 |
| Protection rating | IP00 |
