Indirect solenoid actuated diaphragm valve, G2, 2/2 NC, brass - Norgren 8240700.9100.02400

Norgren 8240700.9100.02400 is a indirect solenoid actuated diaphragm valve with function 2/2 NC and works at port G2 at 0.1 to 10 bar.

Benefits

• High flow rate
• Damped operation
• Clear compact design
• Solenoid interchangeable without tools using Click-on
• Operating pressure 0.1 to 10 bar at nominal diameter 50 mm
• Flow 683 l/min and Kv value 41 m³/h
• Seal material Nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C

Technical data

Applications

The valve is used in water treatment, in cleaning and dosing plants and in machine building wherever gases and liquids have to be switched at 0.1 to 10 bar.

Standards and conformity

The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The electrical connection follows DIN EN 175301-803 form A. As a water valve the series is suitable in accordance with DIN EN 60730-2-8. The housing reaches protection class IP65.
