2/2 way diaphragm valve, solenoid operated, NC, G1/4, 24 V DC, 8 W, EPDM, brass - Norgren 8240014.9101.02400

Norgren ✓ Original product Brand new

The valve with coil code 9101 reaches a Kv value of 1.9 m³/h. Norgren 8240014.9101.02400 is a 2/2 way diaphragm valve with G1/4 port, for 24 V DC and rated for 0.3 to 16 bar.

Net
€147.06
excl. VAT
Item NRG-8240014.9101.02400
Manufacturer no. 8240014.9101.02400
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren 2/2 way diaphragm valve 8240014.9101.02400 has a G1/4 port, is designed for 24 V DC and operates from 0.3 to 16 bar. The valve with EPDM seals reaches a Kv value of 1.9 m³/h.

Benefits

  • Operating pressure 0.3 to 16 bar
  • Flow 23 l/min for fast filling and exhausting
  • Kv value 1.9 m³/h as the sizing figure for the line
  • Nominal diameter 8 mm
  • Electrical connection DIN EN 175301-803 form A for common connectors
  • Power consumption 8 W at the coil

Applications

The 2/2 way diaphragm valve with coil code 9101 is installed in lines that switch gases and liquids.

Technical data

ManufacturerNorgren
Manufacturer part number8240014.9101.02400
Product type2/2 way diaphragm valve
Series82400
Valve function2/2
Normal positionNormally closed (NC)
Actuationsolenoid pilot / spring return
Port sizeG1/4
Nominal diameter8 mm
Operating pressure0.3 to 16 bar
Flow23 l/min
Kv value1.9 m³/h
Mediumgases and liquids
Fluid temperature-10 to 110 °C
Ambient temperature-10 to 50 °C
Body materialbrass
Seal materialEPDM
Valve technologydiaphragm
Voltage24 V DC
Power consumption8 W
Coil code9101
Electrical connectionDIN EN 175301-803 form A
Protection classIP65
Dimensions L x W x H60 x 44 x 78.5 mm
Weight0.47 kg
StandardsDIN EN 175301-803, DIN EN 60730-2-8
RoHScompliant
Hersteller-Nr8240014.9101.02400
Zolltarifnummer84818079
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Nominal size DN [mm]8
Housing materialBrass
Function2/2 closed monostable
Actuation typeElectrical
NormDIN EN 175301-803, DIN EN 60730-2-8
Operating voltage24 V DC
Betriebsdruck max [bar]16
Pneumatic connectionG1/4
Protection ratingIP65
Temperaturbereich-10-50 °C
