2/2 way diaphragm valve, solenoid operated, NC, G1/4, 24 V DC, 8 W, NBR, brass - Norgren 8240002.9109.02400
The 2/2 way diaphragm valve switches directly on 24 V DC from the controller. Norgren 8240002.9109.02400 is a 2/2 way diaphragm valve with G1/4 port, for 24 V DC and rated for 0.1 to 16 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 2/2 way diaphragm valve 8240002.9109.02400 has a G1/4 port, is designed for 24 V DC and operates from 0.1 to 16 bar. The valve from the 82400 series reaches a Kv value of 1.9 m³/h.
Benefits
- Operating pressure 0.1 to 16 bar
- Flow 23 l/min for fast filling and exhausting
- Kv value 1.9 m³/h as the sizing figure for the line
- Nominal diameter 8 mm
- Electrical connection DIN EN 175301-803 form A for common connectors
- Power consumption 8 W at the coil
Applications
The valve with coil code 9109 shuts and opens lines for gases and liquids.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8240002.9109.02400 |
| Product type | 2/2 way diaphragm valve |
| Series | 82400 |
| Valve function | 2/2 |
| Normal position | Normally closed (NC) |
| Actuation | solenoid pilot / spring return |
| Port size | G1/4 |
| Nominal diameter | 8 mm |
| Operating pressure | 0.1 to 16 bar |
| Flow | 23 l/min |
| Kv value | 1.9 m³/h |
| Medium | gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | brass |
| Seal material | nitrile rubber (NBR) |
| Valve technology | diaphragm |
| Voltage | 24 V DC |
| Power consumption | 8 W |
| Coil code | 9109 |
| Electrical connection | DIN EN 175301-803 form A |
| Protection class | IP65 |
| Standards | DIN EN 175301-803, DIN EN 60730-2-8 |
| RoHS | compliant |
| Hersteller-Nr | 8240002.9109.02400 |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Nominal size DN [mm] | 8 |
| Housing material | Brass |
| Function | 2/2 closed monostable |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803, DIN EN 60730-2-8 |
| Operating voltage | 24 V DC |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G1/4 |
| Protection rating | IP65 |
| Temperaturbereich | -10-50 °C |
