2/2 way diaphragm valve, solenoid operated, NC, G1/4, 230 V AC 50 Hz, 15/12 VA, NBR, brass - Norgren 8240000.9101.23050

Norgren ✓ Original product Brand new

The 2/2 way diaphragm valve made of brass stays closed at rest and opens only with the switching signal. Norgren 8240000.9101.23050 is a 2/2 way diaphragm valve with G1/4 port, for 230 V AC and rated for 0.1 to 16 bar.

Net
€126.52
excl. VAT
Item NRG-8240000.9101.23050
Manufacturer no. 8240000.9101.23050
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren 2/2 way diaphragm valve 8240000.9101.23050 has a G1/4 port, is designed for 230 V AC and operates from 0.1 to 16 bar. The valve made of brass stays closed at rest and opens only with the switching signal.

Benefits

  • Operating pressure 0.1 to 16 bar
  • Flow 23 l/min for fast filling and exhausting
  • Kv value 1.9 m³/h as the sizing figure for the line
  • Nominal diameter 8 mm
  • Electrical connection DIN EN 175301-803 form A for common connectors
  • Power consumption 15/12 VA at the coil

Applications

This valve is installed in lines that switch gases and liquids.

Technical data

ManufacturerNorgren
Manufacturer part number8240000.9101.23050
Product type2/2 way diaphragm valve
Series82400
Valve function2/2
Normal positionNormally closed (NC)
Actuationsolenoid pilot / spring return
Port sizeG1/4
Nominal diameter8 mm
Operating pressure0.1 to 16 bar
Flow23 l/min
Kv value1.9 m³/h
Mediumgases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialbrass
Seal materialnitrile rubber (NBR)
Valve technologydiaphragm
Voltage230 V AC, 50 Hz
Power consumption15/12 VA
Coil code9101
Electrical connectionDIN EN 175301-803 form A
Protection classIP65
Dimensions L x W x H78.5 x 60 x 44 mm
StandardsDIN EN 175301-803, DIN EN 60730-2-8
RoHScompliant
Weight0.49 kg
Hersteller-Nr8240000.9101.23050
Zolltarifnummer84818059
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Nominal size DN [mm]8
Housing materialBrass
Function2/2 closed monostable
Actuation typeElectrical
NormDIN EN 175301-803, DIN EN 60730-2-8
Operating voltage230 V AC
Betriebsdruck max [bar]16
Pneumatic connectionG1/4
Protection ratingIP65
Temperaturbereich-10-50 °C
