Diaphragm valve pilot operated, 2/2 NC, G1, DN 25, NBR, 230 V AC - Norgren 8273482.9104.23049

Norgren ✓ Original product Brand new

Switches gases and liquids from 0 bar without differential pressure up to 16 bar, the Norgren diaphragm valve 8273482.9104.23049 reaches a Kv value of 9.5 m³/h at port G1. The 8273482.9104.23049 is normally closed, its coil 9104 runs on 230 V AC at 9 VA with protection class IP65.

Net
€533.77
excl. VAT
Item NRG-8273482.9104.23049
Manufacturer no. 8273482.9104.23049
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The pilot operated Norgren diaphragm valve 8273482.9104.23049 switches gases and liquids at port G1 at 0 to 16 bar. With nominal diameter DN 25 the 8273482.9104.23049 reaches a Kv value of 9.5 m³/h, the permitted fluid temperature is -10 to 90 °C.

Benefits

  • Kv value 9.5 m³/h or Cv value 11 gpm at port G1
  • Operates without differential pressure from 0 bar up to 16 bar
  • Seals made of nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
  • Body made of stainless steel for ambient temperatures of -10 to 50 °C
  • Coil 9104 with 230 V AC and 9 VA, connection to DIN EN 175301-803 form A

Applications

The diaphragm valve 8273482.9104.23049 shuts off and opens lines carrying gases and liquids, for example in cooling circuits, washing and filling systems or compressed air distribution, provided NBR is compatible with the medium.

Standards and conformity

The 8273482.9104.23049 is RoHS compliant and contains an SVHC substance under REACH. The coil connector of the 8273482.9104.23049 follows DIN EN 175301-803 form A. As a water valve the 8273482.9104.23049 is suitable to DIN EN 60730-2-8.

Technical data

ManufacturerNorgren
Part number8273482.9104.23049
Product typediaphragm valve
Series82730
Valve function2/2
Switching functionNC (normally closed)
Actuationpilot operated, solenoid pilot / spring return
Valve technologydiaphragm
Port sizeG1
Nominal diameterDN 25
Operating pressure0 to 16 bar
Kv value9.5 m³/h
Cv value11 gpm
Mediumgases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialstainless steel
Seal materialnitrile rubber (NBR)
Electrical connectionDIN EN 175301-803 form A
Operating voltage230 V AC
Power consumption9 VA
Coil code9104
Protection classIP65
Country of originGermany
RoHScompliant
REACHcontains SVHC substance
WEEEsubject to WEEE
Customs tariff number84818073
Hersteller-Nr8273482.9104.23049
Zolltarifnummer84818073
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Nominal size DN [mm]25
Housing materialStainless steel
Function2/2
DesignDiaphragm valve, servo-controlled
Actuation typeElectrical
NormDIN EN 175301-803, DIN EN 60730-2-8
Betriebsdruck max [bar]16
Pneumatic connectionG1
Protection ratingIP65
Temperaturbereich-10-90 °C
Temperature (max.)90
