Diaphragm valve pilot operated, 2/2 NC, G1, DN 25, EPDM, 24 V AC - Norgren 8273414.9101.02450
Switches gases and liquids at 0.3 to 16 bar with a Kv value of 9.5 m³/h, the Norgren diaphragm valve 8273414.9101.02450 comes with port G1. The 8273414.9101.02450 is normally closed, its coil 9101 runs on 24 V AC at 15/12 VA with protection class IP65.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The pilot operated Norgren diaphragm valve 8273414.9101.02450 switches gases and liquids at port G1 at 0.3 to 16 bar. With nominal diameter DN 25 the 8273414.9101.02450 reaches a Kv value of 9.5 m³/h, the permitted fluid temperature is -10 to 90 °C.
Benefits
- Kv value 9.5 m³/h or Cv value 11 gpm at port G1
- Operating pressure 0.3 to 16 bar at nominal diameter DN 25
- Seals made of EPDM rubber for fluid temperatures of -10 to 90 °C
- Body made of stainless steel for ambient temperatures of -10 to 50 °C
- Coil 9101 with 24 V AC and 15/12 VA, connection to DIN EN 175301-803 form A
Applications
The diaphragm valve 8273414.9101.02450 shuts off and opens lines carrying gases and liquids, for example in cooling circuits, washing and filling systems or compressed air distribution, provided EPDM is compatible with the medium.
Standards and conformity
The 8273414.9101.02450 is RoHS compliant and contains an SVHC substance under REACH. The coil connector of the 8273414.9101.02450 follows DIN EN 175301-803 form A. As a water valve the 8273414.9101.02450 is suitable to DIN EN 60730-2-8.
Technical data
| Manufacturer | Norgren |
|---|---|
| Part number | 8273414.9101.02450 |
| Product type | diaphragm valve |
| Series | 82730 |
| Valve function | 2/2 |
| Switching function | NC (normally closed) |
| Actuation | pilot operated, solenoid pilot / spring return |
| Valve technology | diaphragm |
| Port size | G1 |
| Nominal diameter | DN 25 |
| Operating pressure | 0.3 to 16 bar |
| Kv value | 9.5 m³/h |
| Cv value | 11 gpm |
| Medium | gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | stainless steel |
| Seal material | EPDM rubber |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 24 V AC |
| Power consumption | 15/12 VA |
| Coil code | 9101 |
| Protection class | IP65 |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | contains SVHC substance |
| WEEE | subject to WEEE |
| Customs tariff number | 84812090 |
| Hersteller-Nr | 8273414.9101.02450 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Nominal size DN [mm] | 25 |
| Housing material | Stainless steel |
| Function | 2/2 |
| Design | Diaphragm valve, servo-controlled |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803, DIN EN 60730-2-8 |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G1 |
| Protection rating | IP65 |
| Temperaturbereich | -10-90 °C |
| Temperature (max.) | 90 |
