Diaphragm solenoid valve 2/2 NC, G 1/2, DN 12, 230 V AC, 82400 series - Norgren 8240214.9104.23049

Norgren ✓ Original product Brand new

The Norgren 8240214.9104.23049 diaphragm solenoid valve is closed at rest and passes gases and liquids with Kv 3.8 m³/h through G 1/2 ports. The 8240214.9104.23049 uses coil 9104 for 230 V AC at 9 VA with protection class IP65.

Net
€177.17
excl. VAT
Item NRG-8240214.9104.23049
Manufacturer no. 8240214.9104.23049
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren 8240214.9104.23049 switches gases and liquids through G 1/2 ports with DN 12 nominal size across 0.3 to 16 bar. The 8240214.9104.23049 is driven with 230 V AC at 9 VA via a DIN EN 175301-803 form A connection. A brass body and EPDM seals define the media compatibility of the 8240214.9104.23049.

Benefits

  • Kv value 3.8 m³/h, Cv value 4.4 gpm at DN 12 nominal size
  • Operating pressure 0.3 to 16 bar for gases and liquids
  • Brass body, EPDM seals
  • Fluid temperature -10 to 110 °C, ambient temperature -10 to 50 °C
  • Coil 9104 for 230 V AC, 9 VA, protection class IP65

Applications

The 8240214.9104.23049 suits gases and liquids compatible with EPDM, at fluid temperatures of -10 to 110 °C.

Standards and compliance

The 8240214.9104.23049 uses a DIN EN 175301-803 form A electrical connection. DIN EN 60730-2-8 is specified as standard for the 8240214.9104.23049. The 8240214.9104.23049 is RoHS compliant, contains an SVHC substance under REACH and is covered by the WEEE directive.

Technical data

Product typeDiaphragm solenoid valve
Series82400
Valve function2/2
FunctionNC (normally closed)
ActuationSolenoid pilot / spring return
Valve technologyDiaphragm
Port sizeG 1/2
Nominal diameter12 mm
Operating pressure0.3 to 16 bar
Flow63 l/min
Kv value3.8 m³/h
Cv flow coefficient4.4 gpm
MediumGases and liquids
Fluid temperature-10 to 110 °C
Ambient temperature-10 to 50 °C
Body materialBrass
Seal materialEthylene propylene diene monomer (EPDM)
Electrical connectionDIN EN 175301-803 form A
Operating voltage230 V AC
Power consumption9 VA
Coil code9104
Protection classIP65
Country of originGermany
RoHSCompliant
REACHSVHC substance present
WEEEWEEE
Manufacturer part number8240214.9104.23049
ManufacturerNorgren
Hersteller-Nr8240214.9104.23049
Zolltarifnummer84818079
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/2
Nominal size DN [mm]12
Housing materialBrass
Designdiaphragm valve
Actuation typeElectrical
Medientemperatur [°C]-10 bis 110
NormDIN EN 175301-803, DIN EN 60730-2-8
Betriebsdruck max [bar]16
Protection ratingIP65
