Servo-assisted 2/2-way diaphragm valve NC, G1/2, DN 12, 230 V AC, NBR - Norgren 8240200.9106.23050

Norgren ✓ Original product Brand new

The Norgren servo-assisted diaphragm valve 8240200.9106.23050 switches gases and liquids at port G1/2 from 0.1 to 16 bar and reaches a Kv value of 3.8 m³/h. The solenoid coil 9106 for 230 V AC changes without tools via click-on, and NBR seals handle media from -10 to 90 °C.

Net
€173.49
excl. VAT
Item NRG-8240200.9106.23050
Manufacturer no. 8240200.9106.23050
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren 8240200.9106.23050 is a normally closed servo-assisted diaphragm valve of series 82400 for G1/2 lines with nominal diameter 12 mm. Via the solenoid pilot the 8240200.9106.23050 opens from 0.1 bar, a spring handles the return.

Operating benefits

  • Flow 63 l/min at Kv 3.8 m³/h and nominal diameter 12 mm
  • Operating pressure 0.1 to 16 bar, servo assistance from 0.1 bar
  • Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
  • Solenoid coil 9106 for 230 V AC, power consumption 15/12 VA, tool-free exchange via click-on
  • Damped switching in a compact brass body, protection class IP65

Applications

The Norgren 8240200.9106.23050 is installed in gas lines, cooling circuits and washing and filling systems where gases and liquids at 0.1 to 16 bar and ambient temperatures of -10 to 50 °C have to be controlled.

Standards and conformity

Documented for the Norgren 8240200.9106.23050: plug connection to DIN EN 175301-803 form A, suitability as a water valve to DIN EN 60730-2-8, protection class IP65 and RoHS compliance. Under REACH the valve 8240200.9106.23050 contains an SVHC substance and falls under the WEEE directive.

Technical data

ManufacturerNorgren
Manufacturer part number8240200.9106.23050
Series82400
DesignDiaphragm valve, servo-assisted (indirectly solenoid operated)
Valve function2/2 NC (normally closed)
ActuationSolenoid pilot, spring return
Port sizeG1/2
Nominal diameter12 mm
Operating pressure0.1 to 16 bar
Flow63 l/min
Kv value3.8 m³/h
Cv value4.4 gpm
MediumGases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialBrass
Seal materialNitrile rubber (NBR)
Electrical connectionDIN EN 175301-803 form A
Operating voltage230 V AC
Power consumption15/12 VA
Coil code9106
Protection classIP65
Country of originGermany
RoHScompliant
REACHcontains an SVHC substance
WEEEsubject to WEEE
Hersteller-Nr8240200.9106.23050
Zolltarifnummer84818079
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/2
Nominal size DN [mm]12
Housing materialBrass
Function2/2 closed monostable
Actuation typeElectrical
NormDIN EN 175301-803, DIN EN 60730-2-8
Betriebsdruck max [bar]16
Protection ratingIP65
Temperaturbereich-10-90 °C
Temperature (max.)90
