2/2 way diaphragm valve, solenoid operated, NC, G1/2, 48 V DC, 8 W, NBR, brass - Norgren 8240200.9101.04800

Norgren ✓ Original product Brand new

The valve made of brass switches directly on 48 V DC from the controller. Norgren 8240200.9101.04800 is a 2/2 way diaphragm valve with G1/2 port, for 48 V DC and rated for 0.1 to 16 bar.

Net
€194.59
excl. VAT
Item NRG-8240200.9101.04800
Manufacturer no. 8240200.9101.04800
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren 2/2 way diaphragm valve 8240200.9101.04800 has a G1/2 port, is designed for 48 V DC and operates from 0.1 to 16 bar. The 2/2 way diaphragm valve from the 82400 series switches directly on 48 V DC from the controller.

Benefits

  • Operating pressure 0.1 to 16 bar
  • Flow 63 l/min for fast filling and exhausting
  • Kv value 3.8 m³/h as the sizing figure for the line
  • Nominal diameter 12 mm
  • Electrical connection DIN EN 175301-803 form A for common connectors
  • Power consumption 8 W at the coil

Applications

The 2/2 way diaphragm valve rated 0.1 to 16 bar is installed in lines that switch gases and liquids.

Technical data

ManufacturerNorgren
Manufacturer part number8240200.9101.04800
Product type2/2 way diaphragm valve
Series82400
Valve function2/2
Normal positionNormally closed (NC)
Actuationsolenoid pilot / spring return
Port sizeG1/2
Nominal diameter12 mm
Operating pressure0.1 to 16 bar
Flow63 l/min
Kv value3.8 m³/h
Mediumgases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialbrass
Seal materialnitrile rubber (NBR)
Valve technologydiaphragm
Voltage48 V DC
Power consumption8 W
Coil code9101
Electrical connectionDIN EN 175301-803 form A
Protection classIP65
StandardsDIN EN 175301-803, DIN EN 60730-2-8
RoHScompliant
Hersteller-Nr8240200.9101.04800
Zolltarifnummer84818059
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Nominal size DN [mm]12
Housing materialBrass
Function2/2 closed monostable
Actuation typeElectrical
NormDIN EN 175301-803, DIN EN 60730-2-8
Operating voltage48 V DC
Betriebsdruck max [bar]16
Pneumatic connectionG1/2
Protection ratingIP65
Temperaturbereich-10-50 °C
