Diaphragm solenoid valve 2/2 NC, G 1/2, DN 12, 24 V DC, 82400 series - Norgren 8240200.4682.02400
With Kv 3.8 m³/h at DN 12 and G 1/2 ports, the Norgren 8240200.4682.02400 switches gases and liquids across 0.1 to 16 bar. The 8240200.4682.02400 is driven with 24 V DC at 11.4 W via a DIN EN 175301-803 form A connection.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 8240200.4682.02400 diaphragm solenoid valve is closed at rest and passes gases and liquids with Kv 3.8 m³/h through G 1/2 ports. The 4682 coil of the 8240200.4682.02400 runs on 24 V DC at 11.4 W, protection class IP66 with cable gland, gland not supplied. A brass body and NBR seals define the media compatibility of the 8240200.4682.02400.
Benefits
- Kv value 3.8 m³/h, Cv value 4.4 gpm at DN 12 nominal size
- Operating pressure 0.1 to 16 bar for gases and liquids
- Brass body, NBR seals
- Fluid temperature -10 to 90 °C, ambient temperature -10 to 50 °C
- Coil 4682 for 24 V DC, 11.4 W, protection class IP66 with cable gland, gland not supplied
Applications
The 8240200.4682.02400 suits gases and liquids compatible with NBR, at fluid temperatures of -10 to 90 °C.
Standards and compliance
The 8240200.4682.02400 uses a DIN EN 175301-803 form A electrical connection. DIN EN 60730-2-8 is specified as standard for the 8240200.4682.02400.
Technical data
| Product type | Diaphragm solenoid valve |
|---|---|
| Series | 82400 |
| Valve function | 2/2 |
| Function | NC (normally closed) |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | G 1/2 |
| Nominal diameter | 12 mm |
| Operating pressure | 0.1 to 16 bar |
| Flow | 63 l/min |
| Kv value | 3.8 m³/h |
| Cv flow coefficient | 4.4 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 24 V DC |
| Power consumption | 11.4 W |
| Coil code | 4682 |
| Protection class | IP66 with cable gland, gland not supplied |
| Manufacturer part number | 8240200.4682.02400 |
| Manufacturer | Norgren |
| Hersteller-Nr | 8240200.4682.02400 |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/2 |
| Nominal size DN [mm] | 12 |
| Housing material | Brass |
| Design | diaphragm valve |
| Actuation type | Electrical |
| Medientemperatur [°C] | -10 bis 90 |
| Norm | DIN EN 175301-803, DIN EN 60730-2-8 |
| Betriebsdruck max [bar] | 16 |
| Protection rating | IP66 |
