Servo-assisted 2/2-way diaphragm valve NO, G1-1/4, DN 32, 230 V AC, NBR - Norgren 8240501.9151.23050

Norgren ✓ Original product Brand new

The Norgren servo-assisted diaphragm valve 8240501.9151.23050 switches gases and liquids at port G1-1/4 from 0.1 to 16 bar and reaches a Kv value of 23 m³/h. At port G1-1/4 the coil 9151 runs on 230 V AC, and NBR seals are rated for -10 to 90 °C.

Net
€441.65
excl. VAT
Item NRG-8240501.9151.23050
Manufacturer no. 8240501.9151.23050
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren 8240501.9151.23050 is designed for gases and liquids across 0.1 to 16 bar with port G1-1/4 and nominal diameter 32 mm. Via the solenoid pilot the 8240501.9151.23050 opens from 0.1 bar, a spring handles the return.

Operating benefits

  • Flow 383 l/min at Kv 23 m³/h and nominal diameter 32 mm
  • Operating pressure 0.1 to 16 bar, servo assistance from 0.1 bar
  • Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
  • Solenoid coil 9151 for 230 V AC, power consumption 45/35 VA, tool-free exchange via click-on
  • Damped switching in a compact brass body, protection class IP65

Applications

The 8240501.9151.23050 with port G1-1/4 is used for washing and filling systems, gas lines and cooling circuits whenever gases and liquids have to be switched across 0.1 to 16 bar.

Standards and conformity

Documented for the Norgren 8240501.9151.23050: plug connection to DIN EN 175301-803 form A, suitability as a water valve to DIN EN 60730-2-8, protection class IP65 and RoHS compliance. Under REACH the valve 8240501.9151.23050 contains an SVHC substance and falls under the WEEE directive.

Technical data

ManufacturerNorgren
Manufacturer part number8240501.9151.23050
Series82400
DesignDiaphragm valve, servo-assisted (indirectly solenoid operated)
Valve function2/2 NO (normally open)
ActuationSolenoid pilot, spring return
Port sizeG1-1/4
Nominal diameter32 mm
Operating pressure0.1 to 16 bar
Flow383 l/min
Kv value23 m³/h
Cv value26.6 gpm
MediumGases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialBrass
Seal materialNitrile rubber (NBR)
Electrical connectionDIN EN 175301-803 form A
Operating voltage230 V AC
Power consumption45/35 VA
Coil code9151
Protection classIP65
Dimensions (H x W x L)124.5 x 92 x 132 mm
Weight2.73 kg
Country of originGermany
RoHScompliant
REACHcontains an SVHC substance
WEEEsubject to WEEE
Hersteller-Nr8240501.9151.23050
Zolltarifnummer84812090
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1-1/4
Nominal size DN [mm]32
Housing materialBrass
Function2/2 open monostable
Actuation typeElectrical
NormDIN EN 175301-803, DIN EN 60730-2-8
Betriebsdruck max [bar]16
Protection ratingIP65
Temperaturbereich-10-90 °C
Temperature (max.)90
