Servo-assisted 2/2-way diaphragm valve NO, G1-1/4, DN 32, 110 V AC, NBR - Norgren 8240501.9151.11050
The Norgren servo-assisted diaphragm valve 8240501.9151.11050 switches gases and liquids at port G1-1/4 from 0.1 to 16 bar and reaches a Kv value of 23 m³/h. The solenoid coil 9151 for 110 V AC changes without tools via click-on, and NBR seals handle media from -10 to 90 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a Kv value of 23 m³/h and a nominal diameter of 32 mm the Norgren servo-assisted diaphragm valve 8240501.9151.11050 controls lines with port G1-1/4, normally open. Via the solenoid pilot the 8240501.9151.11050 opens from 0.1 bar, a spring handles the return.
Operating benefits
- Flow 383 l/min at Kv 23 m³/h and nominal diameter 32 mm
- Operating pressure 0.1 to 16 bar, servo assistance from 0.1 bar
- Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
- Solenoid coil 9151 for 110 V AC, power consumption 45/35 VA, tool-free exchange via click-on
- Damped switching in a compact brass body, protection class IP65
Applications
Typical locations for the valve 8240501.9151.11050 are water treatment, cleaning and dosing systems and machine building where gases and liquids at temperatures of -10 to 90 °C have to be switched.
Standards and conformity
Documented for the Norgren 8240501.9151.11050: plug connection to DIN EN 175301-803 form A, suitability as a water valve to DIN EN 60730-2-8, protection class IP65 and RoHS compliance. Under REACH the valve 8240501.9151.11050 contains an SVHC substance and falls under the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8240501.9151.11050 |
| Series | 82400 |
| Design | Diaphragm valve, servo-assisted (indirectly solenoid operated) |
| Valve function | 2/2 NO (normally open) |
| Actuation | Solenoid pilot, spring return |
| Port size | G1-1/4 |
| Nominal diameter | 32 mm |
| Operating pressure | 0.1 to 16 bar |
| Flow | 383 l/min |
| Kv value | 23 m³/h |
| Cv value | 26.6 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 110 V AC |
| Power consumption | 45/35 VA |
| Coil code | 9151 |
| Protection class | IP65 |
| Dimensions (H x W x L) | 124.5 x 92 x 132 mm |
| Weight | 2.73 kg |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | contains an SVHC substance |
| WEEE | subject to WEEE |
| Hersteller-Nr | 8240501.9151.11050 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1-1/4 |
| Nominal size DN [mm] | 32 |
| Housing material | Brass |
| Function | 2/2 open monostable |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803, DIN EN 60730-2-8 |
| Betriebsdruck max [bar] | 16 |
| Protection rating | IP65 |
| Temperaturbereich | -10-90 °C |
| Temperature (max.) | 90 |
