Indirect solenoid actuated diaphragm valve, 2/2 NC, G1-1/4, FPM, 24 V DC - Norgren 8273503.9151.02400

Norgren 8273503.9151.02400 is an indirect solenoid actuated diaphragm valve with function 2/2 NC and works at nominal diameter 32 mm at 0.1 to 16 bar.

Benefits

• High flow rate
• Damped operation
• Clear compact design
• Operating pressure 0.1 to 16 bar at nominal diameter 32 mm
• Kv value 23 m³/h and Cv value 26.6 gpm
• Seal material Fluoropolymer (FPM) for fluid temperatures of -10 to 90 °C

Applications

The valve controls compressed air and gases in filter plants, silos and conveying equipment at nominal diameter 32 mm.

Standards and conformity

The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The electrical connection follows DIN EN 175301-803 form A. As a water valve the series is suitable in accordance with DIN EN 60730-2-8. The housing reaches protection class IP65.
