Diaphragm solenoid valve 2/2 NC, G 1 1/4, DN 32, 230 V AC, 82400 series - Norgren 8240514.9151.23050
With Kv 23 m³/h at DN 32 and G 1 1/4 ports, the Norgren 8240514.9151.23050 switches gases and liquids across 0.3 to 16 bar. The 8240514.9151.23050 is driven with 230 V AC at 45/35 VA via a DIN EN 175301-803 form A connection.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 8240514.9151.23050 diaphragm solenoid valve is closed at rest and passes gases and liquids with Kv 23 m³/h through G 1 1/4 ports. The 9151 coil of the 8240514.9151.23050 runs on 230 V AC at 45/35 VA, protection class IP65. A brass body and EPDM seals define the media compatibility of the 8240514.9151.23050.
Benefits
- Kv value 23 m³/h, Cv value 26.6 gpm at DN 32 nominal size
- Operating pressure 0.3 to 16 bar for gases and liquids
- Brass body, EPDM seals
- Fluid temperature -10 to 110 °C, ambient temperature -10 to 50 °C
- Coil 9151 for 230 V AC, 45/35 VA, protection class IP65
Applications
The 8240514.9151.23050 suits gases and liquids compatible with EPDM, at fluid temperatures of -10 to 110 °C.
Standards and compliance
The 8240514.9151.23050 uses a DIN EN 175301-803 form A electrical connection. DIN EN 60730-2-8 is specified as standard for the 8240514.9151.23050. The 8240514.9151.23050 is RoHS compliant, contains an SVHC substance under REACH and is covered by the WEEE directive.
Technical data
| Product type | Diaphragm solenoid valve |
|---|---|
| Series | 82400 |
| Valve function | 2/2 |
| Function | NC (normally closed) |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | G 1 1/4 |
| Nominal diameter | 32 mm |
| Operating pressure | 0.3 to 16 bar |
| Flow | 383 l/min |
| Kv value | 23 m³/h |
| Cv flow coefficient | 26.6 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 110 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Ethylene propylene diene monomer (EPDM) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 230 V AC |
| Power consumption | 45/35 VA |
| Coil code | 9151 |
| Protection class | IP65 |
| Height | 124.5 mm |
| Width | 92 mm |
| Length | 132 mm |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | WEEE |
| Weight | 2.73 kg |
| Manufacturer part number | 8240514.9151.23050 |
| Manufacturer | Norgren |
| Hersteller-Nr | 8240514.9151.23050 |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1 1/4 |
| Nominal size DN [mm] | 32 |
| Housing material | Brass |
| Design | diaphragm valve |
| Actuation type | Electrical |
| Medientemperatur [°C] | -10 bis 110 |
| Norm | DIN EN 175301-803, DIN EN 60730-2-8 |
| Betriebsdruck max [bar] | 16 |
| Protection rating | IP65 |
