2/2 diaphragm valve, indirect solenoid actuated, NC, G 1 1/4, solenoid/spring, 230 V AC, 383 l/min, DN 32, FPM - Norgren 8240503.6106.23049
For gases and liquids up to 10 bar: the Norgren 8240503.6106.23049 2/2 diaphragm valve passes 383 l/min at the G 1 1/4 port. On 8240503.6106.23049 the coil for 230 V AC changes without tools via Click-on, and FPM seals cover -5 to 80 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 8240503.6106.23049 2/2 diaphragm valve switches gases and liquids at the G 1 1/4 port at an operating pressure of 0.1 to 10 bar. On 8240503.6106.23049: indirect actuation via a solenoid pilot, normally closed (NC) and coil for 230 V AC with coil code 6106.
Benefits
- High throughput of 383 l/min with a Kv value of 23 m³/h
- Operating pressure 0.1 to 10 bar at nominal size 32 mm
- Fluorocarbon rubber (FPM) seals for fluid temperatures of -5 to 80 °C
- Solenoid coil changed without tools via Click-on, coil code 6106
- Coil for 230 V AC drawing 8 VA, connector DIN EN 175301-803 Form A, IP66 protection
- Damped switching movement
Applications
Norgren 8240503.6106.23049 is installed in pipework for gases and liquids, G 1 1/4 port, at fluid temperatures of -5 to 80 °C and ambient temperatures of -10 to 50 °C.
Standards and compliance
For Norgren 8240503.6106.23049: The electrical connector follows DIN EN 175301-803 form A, as a water valve the series is suitable to DIN EN 60730-2-8 and the version is RoHS compliant, under REACH it contains no SVHC substances.
Technical data
| Manufacturer part number | 8240503.6106.23049 |
|---|---|
| Manufacturer | Norgren |
| Product type | 2/2 diaphragm valve |
| Series | 82400 |
| Valve function | 2/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | G 1 1/4 |
| Nominal diameter | 32 mm |
| Operating pressure | 0.1 to 10 bar |
| Flow | 383 l/min |
| Kv value | 23 m³/h |
| Cv flow coefficient | 26.6 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -5 to 80 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Fluoropolymer (FPM) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 230 V AC |
| Power consumption | 8 VA |
| Coil code | 6106 |
| Protection class | IP66 |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | subject to WEEE |
| Customs tariff number | 84818079 |
| Hersteller-Nr | 8240503.6106.23049 |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | 2/2-Wege-Membranventil |
| Thread | G 1 1/4 |
| Nominal size DN [mm] | 32 |
| Housing material | Brass |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803, DIN EN 60730-2-8 |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP66 |
