Servo-assisted 2/2-way diaphragm valve NC, G1-1/4, DN 32, 24 V DC, NBR - Norgren 8240502.9101.02400

Norgren ✓ Original product Brand new

The Norgren servo-assisted diaphragm valve 8240502.9101.02400 switches gases and liquids at port G1-1/4 from 0.1 to 10 bar and reaches a Kv value of 23 m³/h. For the 8240502.9101.02400: coil 9101 with 24 V DC and NBR seals for media from -10 to 90 °C.

Net
€361.18
excl. VAT
Item NRG-8240502.9101.02400
Manufacturer no. 8240502.9101.02400
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With a Kv value of 23 m³/h and a nominal diameter of 32 mm the Norgren servo-assisted diaphragm valve 8240502.9101.02400 controls lines with port G1-1/4, normally closed. Via the solenoid pilot the 8240502.9101.02400 opens from 0.1 bar, a spring handles the return.

Operating benefits

  • Flow 383 l/min at Kv 23 m³/h and nominal diameter 32 mm
  • Operating pressure 0.1 to 10 bar, servo assistance from 0.1 bar
  • Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
  • Solenoid coil 9101 for 24 V DC, power consumption 8 W, tool-free exchange via click-on
  • Damped switching in a compact brass body, protection class IP65

Applications

Typical locations for the valve 8240502.9101.02400 are cooling circuits, washing and filling systems and gas lines where gases and liquids at temperatures of -10 to 90 °C have to be switched.

Standards and conformity

Documented for the Norgren 8240502.9101.02400: plug connection to DIN EN 175301-803 form A, suitability as a water valve to DIN EN 60730-2-8, protection class IP65 and RoHS compliance. Under REACH the valve 8240502.9101.02400 contains an SVHC substance and falls under the WEEE directive.

Technical data

ManufacturerNorgren
Manufacturer part number8240502.9101.02400
Series82400
DesignDiaphragm valve, servo-assisted (indirectly solenoid operated)
Valve function2/2 NC (normally closed)
ActuationSolenoid pilot, spring return
Port sizeG1-1/4
Nominal diameter32 mm
Operating pressure0.1 to 10 bar
Flow383 l/min
Kv value23 m³/h
Cv value26.6 gpm
MediumGases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialBrass
Seal materialNitrile rubber (NBR)
Electrical connectionDIN EN 175301-803 form A
Operating voltage24 V DC
Power consumption8 W
Coil code9101
Protection classIP65
Dimensions (H x W x L)124.5 x 92 x 132 mm
Country of originGermany
RoHScompliant
REACHcontains an SVHC substance
WEEEsubject to WEEE
Weight3 kg
Hersteller-Nr8240502.9101.02400
Zolltarifnummer84812090
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1-1/4
Nominal size DN [mm]32
Housing materialBrass
Function2/2 closed monostable
Actuation typeElectrical
NormDIN EN 175301-803, DIN EN 60730-2-8
Betriebsdruck max [bar]10
Protection ratingIP65
Temperaturbereich-10-90 °C
Temperature (max.)90
