2/2 diaphragm valve, indirect solenoid actuated, NC, G 1 1/4, solenoid/spring, 120 V AC, 383 l/min, DN 32, NBR - Norgren 8240500.9101.12060

Norgren ✓ Original product Brand new

For gases and liquids up to 10 bar: the Norgren 8240500.9101.12060 2/2 diaphragm valve passes 383 l/min at the G 1 1/4 port. On 8240500.9101.12060 the coil for 120 V AC changes without tools via Click-on, and NBR seals cover -10 to 90 °C.

Net
€323.70
excl. VAT
Item NRG-8240500.9101.12060
Manufacturer no. 8240500.9101.12060
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

At the G 1 1/4 port, the Norgren 8240500.9101.12060 2/2 diaphragm valve controls gases and liquids across a pressure range of 0.1 to 10 bar. Specification of 8240500.9101.12060: indirect actuation via a solenoid pilot, normally closed (NC) and coil for 120 V AC with coil code 9101.

Benefits

  • High throughput of 383 l/min with a Kv value of 23 m³/h
  • Operating pressure 0.1 to 10 bar at nominal size 32 mm
  • Nitrile rubber (NBR) seals for fluid temperatures of -10 to 90 °C
  • Solenoid coil changed without tools via Click-on, coil code 9101
  • Coil for 120 V AC drawing 15/12 VA, connector DIN EN 175301-803 Form A, IP65 protection
  • Damped switching movement

Applications

Norgren 8240500.9101.12060 is installed in pipework for gases and liquids, G 1 1/4 port, at fluid temperatures of -10 to 90 °C and ambient temperatures of -10 to 50 °C.

Standards and compliance

For Norgren 8240500.9101.12060: The electrical connector follows DIN EN 175301-803 form A, as a water valve the series is suitable to DIN EN 60730-2-8 and the version is RoHS compliant, under REACH it contains an SVHC substance.

Technical data

Manufacturer part number8240500.9101.12060
ManufacturerNorgren
Product type2/2 diaphragm valve
Series82400
Valve function2/2
FunctionNC
ActuationSolenoid pilot / spring return
Valve technologyDiaphragm
Port sizeG 1 1/4
Nominal diameter32 mm
Operating pressure0.1 to 10 bar
Flow383 l/min
Kv value23 m³/h
Cv flow coefficient26.6 gpm
MediumGases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialBrass
Seal materialNitrile rubber (NBR)
Electrical connectionDIN EN 175301-803 form A
Operating voltage120 V AC
Power consumption15/12 VA
Coil code9101
Protection classIP65
Country of originGermany
RoHSCompliant
REACHSVHC substance present
WEEEsubject to WEEE
Weight2.9 kg
Customs tariff number84818079
Hersteller-Nr8240500.9101.12060
Zolltarifnummer84818079
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Bauform2/2-Wege-Membranventil
ThreadG 1 1/4
Nominal size DN [mm]32
Housing materialBrass
Actuation typeElectrical
NormDIN EN 175301-803, DIN EN 60730-2-8
Betriebsdruck max [bar]10
Protection ratingIP65
Temperaturbereich-10-90 °C
