Servo-assisted 2/2-way diaphragm valve NO, G1-1/2, DN 40, 110 V DC, NBR - Norgren 8240601.9151.11000
The Norgren servo-assisted diaphragm valve 8240601.9151.11000 switches gases and liquids at port G1-1/2 from 0.1 to 16 bar and reaches a Kv value of 25 m³/h. At port G1-1/2 the coil 9151 runs on 110 V DC, and NBR seals are rated for -10 to 90 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 8240601.9151.11000 is designed for gases and liquids across 0.1 to 16 bar with port G1-1/2 and nominal diameter 40 mm. Via the solenoid pilot the 8240601.9151.11000 opens from 0.1 bar, a spring handles the return.
Operating benefits
- Flow 416 l/min at Kv 25 m³/h and nominal diameter 40 mm
- Operating pressure 0.1 to 16 bar, servo assistance from 0.1 bar
- Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
- Solenoid coil 9151 for 110 V DC, power consumption 18 W, tool-free exchange via click-on
- Damped switching in a compact brass body, protection class IP65
Applications
The 8240601.9151.11000 with port G1-1/2 is used for cleaning and dosing systems, machine building and water treatment whenever gases and liquids have to be switched across 0.1 to 16 bar.
Standards and conformity
Documented for the Norgren 8240601.9151.11000: plug connection to DIN EN 175301-803 form A, suitability as a water valve to DIN EN 60730-2-8, protection class IP65 and RoHS compliance. Under REACH the valve 8240601.9151.11000 contains an SVHC substance and falls under the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8240601.9151.11000 |
| Series | 82400 |
| Design | Diaphragm valve, servo-assisted (indirectly solenoid operated) |
| Valve function | 2/2 NO (normally open) |
| Actuation | Solenoid pilot, spring return |
| Port size | G1-1/2 |
| Nominal diameter | 40 mm |
| Operating pressure | 0.1 to 16 bar |
| Flow | 416 l/min |
| Kv value | 25 m³/h |
| Cv value | 28.9 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 110 V DC |
| Power consumption | 18 W |
| Coil code | 9151 |
| Protection class | IP65 |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | contains an SVHC substance |
| WEEE | subject to WEEE |
| Hersteller-Nr | 8240601.9151.11000 |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1-1/2 |
| Nominal size DN [mm] | 40 |
| Housing material | Brass |
| Function | 2/2 open monostable |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803, DIN EN 60730-2-8 |
| Betriebsdruck max [bar] | 16 |
| Protection rating | IP65 |
| Temperaturbereich | -10-90 °C |
| Temperature (max.) | 90 |
