The cap nut version closes the bolted joint with a firm grip. The stated figures are D M 20 and Dk 28,0 mm.
Cap nut, high, DIN 1587, M 20, stainless steel A4, D M 20, Dk 28,0 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€24.06
Item
FL-745513
Manufacturer no.
1587-M20 ES4A
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.1587-M20 ES4A
EAN4050571976248
Customs tariff number73181631
ConditionNew
Artikel
FL-745513
Frequently Bought Together
-
This Item:
€24.06
-
Button head screw ISO 7380-1, thread M 6, length 40 mm, stainless steel A4
€2.06
-
Drill bush DIN 179 form B, short type, bore 2.4 mm, length 6 mm, outside dia 5 mm
€3.67
Total price
When used as a cap nut, the article closes the bolted joint with a firm grip. Decisive here are D M 20 and Dk 28,0 mm. The material used is stainless steel A4.
Benefits
- D M 20
- Dk 28,0 mm
- load-bearing nut thread for repeated assembly, verified by M 16,0 mm
- H 34 mm
- M 16,0 mm
- made of stainless steel A4
Technical data
| material | stainless steel A4 |
|---|---|
| D | M 20 |
| Dk [mm] | 28,0 |
| H [mm] | 34 |
| M [mm] | 16,0 |
| T [mm] | 26,0 |
| S [mm] | 30 |
Fields of application
This design is used for bolted joints on machines, frames and pipework, in this case with Dk 28,0 mm.
Standards
Manufacture and dimensions follow DIN 1587.
| Weight | 0.095000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | 1587-M20 ES4A |
| EAN | 4050571976248 |
| Zolltarifnummer | 73181631 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Edelstahl A4 |
| Norm | DIN 1587 |
