Pneumatic parallel gripper for HRC size 16, stroke per jaw 8 mm HPPH-16-16-NC-P-SR12 - Festo 8205393

Festo ✓ Original product Brand new

With 139 to 151 N gripping force per jaw when closing at 6 bar, the parallel gripper HPPH-16-16-NC-P-SR12 holds prismatic and round parts. 8 mm stroke per jaw, repetition accuracy 0.06 mm, double-acting, ball guide. Runs on 2.5 to 7 bar via push-in connector for 4 mm O.D..

Net
€1,656.00
excl. VAT
Item FES-8205393
Manufacturer no. HPPH-16-16-NC-P-SR12
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Size 16, 139 to 151 N gripping force per jaw when closing at 6 bar: the HPPH-16-16-NC-P-SR12 is a Festo parallel gripper. Both jaws move parallel towards each other. Version HPPH-16-16-NC-P-SR12: double-acting, ball guide, rack and pinion, flat finger mounting.

Benefits

  • 139 to 151 N gripping force per jaw when closing at 6 bar, total gripping force 278 to 302 N
  • Repetition accuracy 0.06 mm
  • 8 mm stroke per jaw, with max. 100 g per external gripper finger
  • Closing time from 90 ms, opening time from 180 ms at 6 bar, operating frequency 1 Hz
  • For HRC: gripping force 116 to 128 N per jaw at 2.5 to 5 bar, certificate TÜV Süd M70132770525.01
  • Gripping force retention when closing

Applications

Typical tasks for the HPPH-16-16-NC-P-SR12 are assembly, feeding and pick-and-place in automated systems, at -5 to 50 °C ambient temperature. Gripper fingers are mounted on the jaws, each external finger may weigh up to 100 g. Integrated displacement encoder for position detection. For human-robot collaboration Festo recommends a workpiece weight of 1 kg. Shipping weight 0.8 kg.

Technical data

Size16
Total stroke16 mm
Stroke per gripper jaw8 mm
Max. angular gripper jaw backlash ax, ay0°
Max. gripper jaw backlash Sz0 mm
Repetition accuracy, gripper0.06 mm
Number of gripper jaws2
Drive systemPneumatic
Mounting positionAny
Mode of operationDouble-acting
CushioningAt one end, Not adjustable
Gripper functionParallel
Gripping force retentionDuring closing
DesignFlat mounting method for gripper fingers, Guidance, Rack and pinion, With gripper finger, Pneumatic gripper, Positively driven motion sequence
GuideBall guide
Position detectionVia integrated displacement encoder
Switching status indicationBlue LED, switching status via signal input
Operating pressure2.5 to 7 bar
Operating pressure HRC2.5 to 5 bar
Max. operating frequency of gripper1 Hz
Min. opening time at 6 bar180 ms
Min. closing time at 6 bar90 ms
Max. mass per external gripper finger100 g
Max. current consumption100 mA
Nominal operating voltage DC24 V
Switching outputPNP
Switching inputPNP
Permissible voltage fluctuations±10%
ApprovalRCM
CE mark (see declaration of conformity)To EU EMC Directive, In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)To UK instructions for EMC, To UK RoHS instructions
Certificate issuing authorityTÜV Süd M70132770525.01
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating mediumLubricated operation possible, after that always operate lubricated
Shock resistanceShock test with severity level 2 to FN 942017-5 and EN 60068-2-27
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Vibration resistanceTransport application test with severity level 2 to FN 942017-4 and EN 60068-2-6
Relative air humidity0 - 90%, Non-condensing
Sound pressure level75 dB(A)
Degree of protectionIP40
Ambient temperature-5 to 50 °C
Total gripping force, closing at 6 bar278 to 302 N
Gripping force per gripper jaw, closing at 6 bar139 to 151 N
Total gripping force HRC, closing232 to 256 N
Gripping force per gripper jaw HRC, closing116 to 128 N
Note on gripping forceDependent on the stroke, With integrated compression spring
Theoretical spring force per gripper jaw, closing23.3 to 34.9 N
Mass moment of inertia0.6 kgcm²
Max. force on gripper jaw Fz static176 N
Max. moment Mx2.8 Nm
Max. moment My1.4 Nm
Max. moment Mz1.4 Nm
Bending radius, fixed cable26 mm
Bending radius, moving cable52 mm
Maintenance intervalLifetime lubrication
Product weight680 g
Recommended workpiece weight for MRK1 kg
Electrical connection 1, functionField device side
Electrical connection 1, connection typeCable with socket
Electrical connection 1, cable outletAngled
Electrical connection 1, designRound
Electrical connection 1, connector systemM8x1, A-coded, to EN 61076-2-104
Electrical connection 1, number of connections/cores8
Electrical connection 1, used connections/cores6
Electrical connection 1, connection pattern997559
Electrical connection 1, tightening torque0.2 Nm
Type of mountingWith mounting kit, To ISO 9409
Pneumatic connectionFor push-in connector O.D. 4 mm
Note on materialsRoHS compliant
Cover materialReinforced PA
Material springHigh-alloy stainless steel
Housing materialAnodised wrought aluminium alloy
Gripper jaw materialHigh-alloy steel
Material pistonWrought aluminium alloy, anodised
Piston seal materialTPE-U(PU)
O-ring materialHNBR, NBR
Screw materialGalvanised steel, High-alloy steel
Gear wheel materialHigh-alloy steel
Gripper finger materialWrought aluminium alloy, anodised
Weight0.8 kg
ManufacturerFesto
Hersteller-NrHPPH-16-16-NC-P-SR12
EAN4052568651848
Zolltarifnummer84798997
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
MediumCompressed air
Functiondouble-acting
Actuation typepneumatic
Betriebsdruck max [bar]7
Protection ratingIP40
Temperature (max.)50
