Pneumatic parallel gripper size 16, stroke per jaw 8 mm HPPF-16-16-A - Festo 8105829

Festo ✓ Original product Brand new

The parallel gripper HPPF-16-16-A holds prismatic and round parts and delivers 109.1 N gripping force per jaw when closing at 6 bar. 8 mm stroke per jaw, repetition accuracy 0.06 mm, double-acting, ball guide. Runs on 1 to 7 bar via M5 port. Position detection with proximity switches.

Net
€289.47
excl. VAT
Item FES-8105829
Manufacturer no. HPPF-16-16-A
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Size 16, 109.1 N gripping force per jaw when closing at 6 bar: the HPPF-16-16-A is a Festo parallel gripper. Both jaws move parallel towards each other. Version HPPF-16-16-A: double-acting, ball guide, rack and pinion, flat finger mounting.

Benefits

  • 109.1 N gripping force per jaw when closing at 6 bar, total gripping force 218.2 N
  • Repetition accuracy 0.06 mm
  • 8 mm stroke per jaw, with max. 335 g per external gripper finger
  • Closing time from 47 ms, opening time from 55 ms at 6 bar, operating frequency 1 Hz
  • Corrosion resistance class CRC 0, ambient temperature -10 to 60 °C

Applications

Typical tasks for the HPPF-16-16-A are assembly, feeding and pick-and-place in automated systems, at -10 to 60 °C ambient temperature. Gripper fingers are mounted on the jaws, each external finger may weigh up to 335 g. Position detection with proximity switches. The HPPF-16-16-A is suitable for battery production with reduced Cu/Zn/Ni values (F1a). Shipping weight 0.38 kg.

Technical data

Size16
Total stroke16 mm
Stroke per gripper jaw8 mm
Max. angular gripper jaw backlash ax, ay0°
Max. gripper jaw backlash Sz0 mm
Repetition accuracy, gripper0.06 mm
Number of gripper jaws2
Drive systemPneumatic
Mounting positionAny
Mode of operationDouble-acting
CushioningElastic cushioning rings/plates at both ends
Gripper functionParallel
Gripping force retentionNone
DesignFlat mounting method for gripper fingers, Rack and pinion, Positively driven motion sequence
GuideBall guide
Position detectionVia proximity switch
VariantsVariant without copper, zinc or nickel as main constituent (except nickel in steel, chemically nickel-plated surfaces, PCBs, cables, connectors and coils)
Operating pressure1 to 7 bar
Max. operating frequency of gripper1 Hz
Min. opening time at 6 bar55 ms
Min. closing time at 6 bar47 ms
Max. mass per external gripper finger335 g
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating mediumLubricated operation possible, after that always operate lubricated
Corrosion resistance class CRC0 - No corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Suitability for the production of Li-ion batteriesSuitable for battery production with reduced Cu/Zn/Ni values (F1a)
Ambient temperature-10 to 60 °C
Total gripping force, opening at 6 bar218.2 N
Total gripping force, closing at 6 bar218.2 N
Gripping force per gripper jaw, opening at 6 bar109.1 N
Gripping force per gripper jaw, closing at 6 bar109.1 N
Max. force on gripper jaw Fz static180 N
Max. moment Mx4.4 Nm
Max. moment My2.2 Nm
Max. moment Mz2.2 Nm
Product weight366 g
Type of mountingDirect mounting via through-hole, Direct mounting via thread
Pneumatic connectionM5
Note on materialsRoHS compliant
Cover cap materialWrought aluminium alloy, anodised
Cover materialAnodised wrought aluminium alloy
End plate materialHigh-alloy stainless steel
Housing materialAnodised wrought aluminium alloy
Gripper jaw materialHigh-alloy steel
Piston seal materialTPE-U(PU)
O-ring materialNBR
Screw materialCoated steel
Gear rack materialHigh-alloy stainless steel
Weight0.38 kg
ManufacturerFesto
Hersteller-NrHPPF-16-16-A
EAN4052568586140
Zolltarifnummer84798997
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
ThreadM5
MediumCompressed air
Functiondouble-acting
Actuation typepneumatic
Betriebsdruck max [bar]7
Temperaturbereich-10-60 °C
Temperature (max.)60
