Foot mounting size 20 to 25, in galvanised steel HBN-S-20/25X2 - Festo 5407847
The foot mounting HBN-S-20/25X2 mounts the drive parallel to its axis on a flat surface. It is designed for size 20 to 25. Festo specifies galvanised steel as the material. Festo classifies the part as CRC 1 (low corrosion stress). Usable at -40 to 150 °C ambient temperature. Product weight 165 g.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The foot mounting HBN-S-20/25X2 mounts the drive parallel to its axis on a flat surface. It is designed for size 20 to 25. Festo specifies galvanised steel as the material.
At a glance
- Material mounting: galvanised steel
- Corrosion resistance class CRC 1 - low corrosion stress
- Ambient temperature -40 to 150 °C
- LABS (PWIS) conformity VDMA24364-B1/B2-L
- Copper content max. 1 % (exceptions according to Festo)
Use
It is used in plant and special machine building, where the HBN-S-20/25X2 connects drives of size 20 to 25 to the machine.
Technical data
| Order type | HBN-S-20/25X2 |
|---|---|
| Festo part number | 5407847 |
| Size | 20 to 25 |
| Mounting position | any |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Suitability for the production of Li-ion batteries | copper content max. 1 % (exceptions according to Festo) |
| Ambient temperature | -40 to 150 °C |
| Product weight | 165 g |
| Note on materials | RoHS compliant |
| Material mounting | galvanised steel |
| Material nut | steel, galvanised |
| Customs tariff number | 73269098 |
| Weight | 0.155 kg |
| Manufacturer | Festo |
| Hersteller-Nr | HBN-S-20/25X2 |
| EAN | 4052568423346 |
| Zolltarifnummer | 73269098 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Galvanised steel |
| Series | HBN |
| Temperaturbereich | -40-150 °C |
| Temperature (max.) | 150 |
