Gripper finger made of aluminium size 16 HAFH-B30-16-45-N - Festo 8207226
The gripper finger HAFH-B30-16-45-N made of anodised wrought aluminium alloy is screwed directly onto the size 16 gripper. Gripper jaws made of anodised wrought aluminium alloy, cap made of POM, plate made of anodised wrought aluminium alloy.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The gripper finger HAFH-B30-16-45-N made of anodised wrought aluminium alloy is screwed directly onto the size 16 gripper. Gripper jaws made of anodised wrought aluminium alloy, cap made of POM, plate made of anodised wrought aluminium alloy, product weight 42 g.
Benefits
- Gripper jaws made of anodised wrought aluminium alloy, cap made of POM, plate made of anodised wrought aluminium alloy
- Corrosion resistance class CRC 2 for moderate corrosion stress
- Ambient temperature -5 to 50 °C
- LABS (PWIS) conformity VDMA24364 zone III
- Product weight 42 g
- RoHS compliant
Applications
The HAFH-B30-16-45-N belongs to the Festo gripper accessories and is used on size 16 grippers, the cap is made of POM.
Technical data
| Order type | HAFH-B30-16-45-N |
|---|---|
| Festo part number | 8207226 |
| Size | 16 |
| Mounting position | any |
| Design | for grippers |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | -5 to 50 °C |
| Product weight | 42 g |
| Type of mounting | screwed onto gripper |
| Note on materials | RoHS compliant |
| Material gripper jaws | anodised wrought aluminium alloy |
| Material cap | POM |
| Material plate | anodised wrought aluminium alloy |
| Material screws | galvanised steel |
| Material centering pins | steel |
| Gripper finger material | wrought aluminium alloy, anodised |
| Customs tariff number | 84799070 |
| Weight | 0.048 kg |
| Manufacturer | Festo |
| Hersteller-Nr | HAFH-B30-16-45-N |
| EAN | 4052568651855 |
| Zolltarifnummer | 84799070 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Aluminium, anodised |
| Temperature (max.) | 50 |
