One-way flow control valve for exhaust air, 1/2 NPT and QB-1/2, 6114.41 l/min GRLA-1/2-QB-1/2-U - Festo 564847

Festo ✓ Original product Brand new

The GRLA-1/2-QB-1/2-U one-way flow control valve sets the speed of a cylinder via the exhaust air. Key data: ports 1/2 NPT and QB-1/2, nominal flow in flow control direction 6114.41 l/min, operating pressure -0.951 to 7.998 bar. Seals made of NBR, ambient temperature 0 to 60 °C. Weight 110 g.

Net
€31.92
excl. VAT
Item FES-564847
Manufacturer no. GRLA-1/2-QB-1/2-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

6114.41 l/min standard nominal flow rate in flow control direction: the GRLA-1/2-QB-1/2-U one-way flow control valve sets the speed of a cylinder via the exhaust air. The return flow of 4716.102 to 6241.525 l/min passes freely through the check valve.

Benefits

  • Flow rate: standard nominal flow rate in flow control direction 6114.41 l/min, in non-return direction 4716.102 to 6241.525 l/min
  • Pressure range: -0.951 to 7.998 bar operating pressure
  • Connections: QB-1/2, 1/2 NPT
  • Paint compatibility: LABS conformity VDMA24364 zone III
  • Materials: seals NBR
  • Temperature: 0 to 60 °C ambient temperature

Applications

Used on double-acting cylinders, usually directly in the cylinder port. Operating medium: compressed air to ISO 8573-1:2010 [7:4:4]. Mounting: screw-in, with male thread. Once lubricated, lubrication must continue.

Technical data

TypeGRLA-1/2-QB-1/2-U
Festo part number564847
Valve functionExhaust air one-way flow control function
Pneumatic connection, port 1QB-1/2
Pneumatic connection, port 21/2 NPT
Type of actuationManual
Adjustment componentSlotted screw
Type of mountingScrew-in, with male thread
Standard nominal flow rate in flow control direction6114.41 l/min
Standard nominal flow rate in non-return direction4716.102 to 6241.525 l/min
Ambient temperature0 to 60 °C
Mounting positionAny
Operating pressure, full temperature range-0.951 to 7.998 bar
Standard flow rate in flow control direction (6 to 0 bar)9673.7 l/min
Standard flow rate in non-return direction (6 to 0 bar)9673.729 to 10055.085 l/min
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot mediumLubricated operation possible (then required for further operation)
LABS (PWIS) conformityVDMA24364 zone III
Medium temperature0 to 60 °C
Max. tightening torque28.065 Nm
Product weight119.07 g
Material screw-in studNickel-plated brass
Note on materialsRoHS-compliant
Material sealsNBR
Material banjo boltNickel-plated brass
Material release ringPOM
Material knurled headNickel-plated brass
Material adjusting screwNickel-plated brass
Material swivel fittingReinforced PBT
Weight (shipping)110 g
Weight0.11 kg
ManufacturerFesto
Hersteller-NrGRLA-1/2-QB-1/2-U
EAN4052568367206
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadNPT 1/2
Seal materialNBR
MediumCompressed air
FunctionExhaust air throttle check valve function
Actuation typeManually
SeriesGRLA
Betriebsdruck max [bar]7
Temperaturbereich0-60 °C
Temperature (max.)60
