Threaded liner with round thread, thread Rd 160 x 1/4", DN 125 mm, pipe 139.7 mm, 1.4301

The threaded liner with round thread carries the product through a joint that opens without any tooling effort. 1.4301 determines the load capacity and the corrosion behaviour. The joint is created via the round thread Rd 160 x 1/4". The nominal size is stated as 125 mm.

Benefits

• At 125 mm the nominal size is defined in the data sheet and can be planned in advance.
• The joint opens by hand with 1 slotted nut, no tools are needed for cleaning.
• The smooth inner face leaves no dead spaces at the 2 sealing points in which product could remain.
• The round thread Rd 160 x 1/4" fits the existing port without an adapter.

Applications

Dairy and beverage plants, food processing, plants with regular cleaning. The selection follows the existing port and the operating load of the system.

Standards and conformity

The following standards are documented for this component: dimensions to ISO pipes (similar to DIN). The materials comply with the regulations FDA 21 CFR 177.2600, FDA 21 CFR 177.1550 and (EC) 1935/2004.
