Tube union, straight design, tube stud 20 S, second tube stud 20 S, stainless steel 1.4571

The tube union brings a tube stud 20 S and a second tube stud 20 S together. The operating pressure reaches up to 400 bar. The straight design carries the medium through the part without deflection.

Benefits

• The temperature range from -20 °C to +200 °C covers cold installation and warm machine surroundings
• The material stainless steel 1.4571 stays resistant without additional coating in the range from -20 °C to +200 °C
• The heavy series with the code S follows the dimension series to ISO 8434-1
• The cutting ring bites into the tube wall and holds the tube even under pressure surges
• With tube stud 20 S the size is fixed, so no reworking of the line is required
• The operating pressure up to 400 bar is released for this size

Applications

Repair of existing tube fittings, test benches and power unit construction, hydraulic lines in machine and plant engineering, pipework on presses and pumps.

Standards and conformity

The tube fitting follows the design of cutting ring tube fittings to ISO 8434-1, formerly DIN 2353.
