Tube union, straight design, tube stud 12 L, second tube stud 12 L, stainless steel 1.4571

This tube union joins a tube stud 12 L and a second tube stud 12 L in one part. The operating pressure reaches up to 315 bar. The straight design carries the medium through the part without deflection.

Benefits

• The cutting ring bites into the tube wall and holds the tube even under pressure surges
• With tube stud 12 L the size is fixed, so no reworking of the line is required
• The operating pressure up to 315 bar is released for this size
• The temperature range from -20 °C to +200 °C covers cold installation and warm machine surroundings
• The material stainless steel 1.4571 stays resistant without additional coating in the range from -20 °C to +200 °C
• The light series with the code L follows the dimension series to ISO 8434-1

Technical data

Applications

Pipework on presses and pumps, repair of existing tube fittings, test benches and power unit construction, hydraulic lines in machine and plant engineering.

Standards and conformity

The tube fitting follows the design of cutting ring tube fittings to ISO 8434-1, formerly DIN 2353.
