Flange mounting size 1 1/4", in aluminium, CRC 2 FZF-1 1/4" - Festo 546556
The flange mounting FZF-1 1/4" fixes the drive at its end face to a machine wall or plate. It is designed for size 1 1/4". Festo specifies wrought aluminium alloy, anodised as the material. Corrosion class: CRC 2 (moderate corrosion stress). Usable at -40 to 150 °C ambient temperature.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The flange mounting FZF-1 1/4" fixes the drive at its end face to a machine wall or plate. It is designed for size 1 1/4". Festo specifies wrought aluminium alloy, anodised as the material.
Benefits
- Material mounting: wrought aluminium alloy, anodised
- Corrosion resistance class CRC 2 - moderate corrosion stress
- Ambient temperature -40 to 150 °C
- LABS (PWIS) conformity VDMA24364-B1/B2-L
Typical applications
The FZF-1 1/4" is used in machine and fixture construction when installing pneumatic drives of size 1 1/4".
Technical data
| Order type | FZF-1 1/4" |
|---|---|
| Festo part number | 546556 |
| Size | 1 1/4" |
| Mounting position | any |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -40 to 150 °C |
| Product weight | 78 g |
| Note on materials | RoHS compliant |
| Material mounting | wrought aluminium alloy, anodised |
| Material screws | steel, galvanised |
| Customs tariff number | 90330090 |
| Manufacturer | Festo |
| Hersteller-Nr | FZF-1 1/4" |
| EAN | 4052568354145 |
| Zolltarifnummer | 90330090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | FZF |
| Temperaturbereich | -40-150 °C |
| Temperature (max.) | 150 |
