Fine filter G 1/4", 0.3 µm, plastic bowl with protective cage, semi-automatic drain, Futura 1 series - Fluidics equipment
Removes fine particles down to 0.3 µm and oil aerosols from compressed air, for example upstream of regulators, valve terminals or measuring devices. Port G 1/4", inlet pressure 1.5 to 16 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The fine filter with 0.3 µm sits downstream of the pre-filter and supplies much cleaner air to sensitive consumers. Thread G 1/4" for inlet pressure 1.5 to 16 bar. Fits units of the Futura 1 series.
Benefits
- Plastic bowl with protective cage, semi-automatic condensate drain
- Condensate volume up to 12 cm³
- Optimum flow rate 300 l/min at the G 1/4" port
- Inlet pressure 1.5 to 16 bar
- PA 66 GF60 for -10 to +50 °C
- Standards according to data sheet: Directive 2014/34/EU
Applications
Air treatment lines in production, maintenance and workshops where clean, defined compressed air is required.
Technical data
| Version | fine filter (0.3 µm) |
|---|---|
| Series | Futura 1 |
| Port thread | G 1/4" |
| Bowl version | plastic bowl with protective cage |
| Condensate drain | semi-automatic |
| Max. condensate volume | 12 cm³ |
| Optimum flow rate | 300 l/min |
| Dimension H | 169 mm |
| Dimension H1 | 130 mm |
| Dimension L | 52 mm |
| Inlet pressure | 1.5 to 16 bar |
| Body material | PA 66 GF60 |
| Temperature range | -10 to +50 °C |
| Media | compressed air, neutral gases |
| Standards | Directive 2014/34/EU |
| Accessories (separate) | mounting bracket, connecting kit, connecting kit with wall bracket, replacement filter, differential pressure indicator, differential pressure gauge |
| Weight | 280 g |
| Customs tariff number | 84213925 |
| EAN | 4050571310677 |
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | FV 14 F |
| Zolltarifnummer | 84213925 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Feinfilter (0,3 µm) |
| Behälterausführung | Kunststoffbehälter mit Schutzkorb |
| Thread | G 1/4 |
| Housing material | PA66 GF60 |
| Medium | Compressed air, neutral gases |
| Inlet pressure max. [bar] | 16 |
| Filter grade [µm] | 0,3 |
| Befestigungswinkel | W 1 F |
| Temperaturbereich | -10-50 °C |
