This suction cup holder connects the suction cup to the vacuum line by a thread. What counts here is a nominal width of 8.5 mm. The dimensions come to thread G 1/8" (female thread), nominal width DN 8.5 mm, height H2 6.0 mm.
Aluminium suction cup holder, type L, thread G 1/8" (female thread), nominal width DN 8.5 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€6.45
€5.42
Item
FL-228820
Manufacturer no.
VSH L18 I
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VSH L18 I
EAN4050571726409
Customs tariff number76161000
ConditionNew
Artikel
FL-228820
Frequently Bought Together
-
This Item:
€6.45 €5.42
-
Spare filter element for vacuum filter
€163.76 €137.61
-
Spare filter element for vacuum filter
€33.74 €28.35
The suction cup holder connects the suction cup to the vacuum line by a thread. In addition the sheet lists a height H2 of 6.0 mm. This version comes with thread G 1/8" (female thread), nominal width DN 8.5 mm and height H2 6.0 mm.
Benefits
- Nominal width DN 8.5 mm.
- Dimension D1 of 21.0 mm as per the data sheet.
- Listed with Dimension D2 17.5 mm.
- Dimension H1 3.0 mm.
- Dimension H2 of 6.0 mm as per the data sheet.
Technical data
| Version | aluminium suction cup holder |
|---|---|
| Holder type | L |
| Thread G | G 1/8" (female thread) |
| Nominal width DN [mm] | 8.5 |
| Dimension D1 [mm] | 21.0 |
| Dimension D2 [mm] | 17.5 |
| Dimension H1 [mm] | 3.0 |
| Dimension H2 [mm] | 6.0 |
| Form number | 7 |
Applications
Typical use is anywhere the suction cup holder has to connect the suction cup to the vacuum line.
| Hersteller-Nr | VSH L18 I |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571726409 |
| Weight | 0.003700 |
| Zolltarifnummer | 76161000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
