This suction cup holder connects the suction cup to the vacuum line by a thread. What counts here is a nominal width of 2.4 mm. Dimension thread M 5 (AG), nominal width DN 2.4 mm, height H2 5.5 mm.
Aluminium suction cup holder, type H, thread M 5 (AG), nominal width DN 2.4 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€2.73
Item
FL-228810
Manufacturer no.
VSH H50
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VSH H50
EAN4050571726379
Customs tariff number76161000
ConditionNew
Artikel
FL-228810
Frequently Bought Together
-
This Item:
€2.73
-
Precision vacuum regulator, port G 3/4", control range -1 to 0.7 bar
€2,381.35
-
Miniature vacuum regulator for mounting at the suction cup, port M 5, control range -0.85 to 0 bar
€132.71
Total price
The suction cup holder connects the suction cup to the vacuum line by a thread. In addition the sheet lists a height H2 of 5.5 mm. Its rating is a nominal width of 2.4 mm.
Benefits
- Nominal width DN of 2.4 mm as per the data sheet.
- Listed with Dimension D1 5.5 mm.
- Dimension D2 7.3 mm.
- Width across flats SW of 8 mm as per the data sheet.
- Listed with Dimension H1 2.5 mm.
Technical data
| Version | aluminium suction cup holder |
|---|---|
| Holder type | H |
| Thread G | M 5 (AG) |
| Nominal width DN [mm] | 2.4 |
| Dimension D1 [mm] | 5.5 |
| Dimension D2 [mm] | 7.3 |
| Width across flats SW [mm] | 8 |
| Dimension H1 [mm] | 2.5 |
| Dimension H2 [mm] | 5.5 |
| Dimension H3 [mm] | 15.5 |
| Form number | 1 |
Applications
Typical use is anywhere the suction cup holder has to connect the suction cup to the vacuum line.
| Hersteller-Nr | VSH H50 |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571726379 |
| Weight | 0.001300 |
| Zolltarifnummer | 76161000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
