The flat suction cup holds the workpiece on the suction face by vacuum. The underlying rating is a suction cup diameter of 40 mm. Ø 40 mm, stroke 3 mm, holder type L, colour transparent in silicone, 50 Shore A.
Flat suction cup, Ø 40 mm, stroke 3 mm, silicone, 50 Shore A, transparent, fine lip
FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€13.99 €11.76
Item FL-228698
Manufacturer no. VS 40 FF SI
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.VS 40 FF SI
EAN4050571725211
Customs tariff number84879090
ConditionNew
Artikel
FL-228698
Frequently Bought Together
- This Item: €13.99 €11.76
- Spring plunger M 5 (IG)xM 5 (Female thread), stroke 5mm, Standard €37.19 €31.25
- Flat suction cup, Ø 22 mm, stroke 1 mm, CR (50A), black, with a support rib €11.19 €9.40
Once installed, the flat suction cup holds the workpiece on the suction face by vacuum. It is produced from silicone, 50 Shore A. The data give suction cup diameter 40 mm, stroke 3 mm, holder type L and colour transparent.
Benefits
- Suction cup diameter D Ø 40 mm.
- Stroke of 3 mm as per the data sheet.
- Dimension D3 of 26 mm as per the data sheet.
- Listed with Dimension D4 17.5 mm.
- Dimension h 12.5 mm.
Technical data
| Material | silicone, 50 Shore A |
|---|---|
| Suction cup diameter D [mm] | Ø 40 |
| Stroke [mm] | 3 |
| Colour | transparent |
| Connection (female thread) | G 1/8" |
| Dimension D3 [mm] | 26 |
| Dimension D4 [mm] | 17.5 |
| Dimension h [mm] | 12.5 |
| Height including holder [mm] | 12.5 |
| Dimension h3 [mm] | 6.0 |
| Dimension h4 [mm] | 2.9 |
| Temperature range [°C] | -40 to +200 |
| Holder type | L |
| Suction cup version | fine lip |
Applications
Typical use is anywhere the flat suction cup has to pick up and hold workpieces by vacuum.
| Hersteller-Nr | VS 40 FF SI |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571725211 |
| Weight | 0.005100 |
| Zolltarifnummer | 84879090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
