This bellows suction cup holds the workpiece on the suction face by vacuum. A key figure is a suction cup diameter of 40 mm. Size Ø 40 mm, stroke 20 mm, holder type G, colour red, material silicone, 60 Shore A.
Bellows suction cup for vacuum handling, Ø 40 mm, stroke 20 mm, silicone, 60 Shore A
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€8.70
€7.31
Item
FL-228788
Manufacturer no.
VS 40 B2 SI
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VS 40 B2 SI
EAN4050571725198
Customs tariff number84879090
ConditionNew
Artikel
FL-228788
Frequently Bought Together
-
This Item:
€8.70 €7.31
-
Flat suction cup, Ø 70 mm, stroke 6 mm, NR (50A), beige, fine lip
€29.77 €25.02
-
Free-flow silencer for exhaust air, port G 1/4", diameter 19 mm, length 46 mm
€32.03 €26.92
As a bellows suction cup the article holds the workpiece on the suction face by vacuum. The data sheet gives a suction cup diameter of 40 mm. The stated figures are suction cup diameter 40 mm, stroke 20 mm, holder type G and colour red.
Benefits
- Suction cup diameter D of Ø 40 mm as per the data sheet.
- Listed with Stroke 20 mm.
- Dimension D1 8 mm.
- Dimension D2 of 19 mm as per the data sheet.
- Listed with Dimension D3 18 mm.
Technical data
| Material | silicone, 60 Shore A |
|---|---|
| Suction cup diameter D [mm] | Ø 40 |
| Stroke [mm] | 20 |
| Colour | red |
| Connection (female thread) | G 1/4" |
| Connection (male thread) | G 1/4" |
| Dimension D1 [mm] | 8 |
| Dimension D2 [mm] | 19 |
| Dimension D3 [mm] | 18 |
| Dimension h [mm] | 45 |
| Suction cup height H [mm] | 60 |
| Temperature range [°C] | -40 to +200 |
| Holder type | G |
| Bellows form | 2.5 folds |
Applications
The bellows suction cup is used wherever it has to pick up and hold workpieces by vacuum.
| Hersteller-Nr | VS 40 B2 SI |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571725198 |
| Weight | 0.021000 |
| Zolltarifnummer | 84879090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
