In service the bellows suction cup holds the workpiece on the suction face by vacuum. The decisive figure is a suction cup diameter of 40 mm. Dimensions Ø 40 mm, stroke 20 mm, holder type G, colour blue, made of PUR (55A).
Bellows suction cup for vacuum handling, Ø 40 mm, stroke 20 mm, PUR (55A)
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€13.52
€11.36
Item
FL-228789
Manufacturer no.
VS 40 B2 PUR
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VS 40 B2 PUR
EAN4050571725181
Customs tariff number84879090
ConditionNew
Artikel
FL-228789
Frequently Bought Together
-
This Item:
€13.52 €11.36
-
3/2-way vacuum valve, port G 1/2", nominal width DN 11 mm, control voltage 230 V AC
€1,361.24 €1,143.90
-
Bellows suction cup for vacuum handling, Ø 6 mm, stroke 2 mm, CR (60A)
€3.21 €2.70
This bellows suction cup holds the workpiece on the suction face by vacuum. The stated material is PUR (55A). The data state a suction cup diameter of 40 mm.
Benefits
- Listed with Suction cup diameter D Ø 40 mm.
- Stroke 20 mm.
- Dimension D1 of 8 mm as per the data sheet.
- Listed with Dimension D2 19 mm.
- Dimension D3 18 mm.
Technical data
| Material | PUR (55A) |
|---|---|
| Suction cup diameter D [mm] | Ø 40 |
| Stroke [mm] | 20 |
| Colour | blue |
| Connection (female thread) | G 1/4" |
| Connection (male thread) | G 1/4" |
| Dimension D1 [mm] | 8 |
| Dimension D2 [mm] | 19 |
| Dimension D3 [mm] | 18 |
| Dimension h [mm] | 45 |
| Suction cup height H [mm] | 60 |
| Temperature range [°C] | -20 to +80 |
| Holder type | G |
| Bellows form | 2.5 folds |
Applications
The bellows suction cup is used wherever it has to pick up and hold workpieces by vacuum.
| Hersteller-Nr | VS 40 B2 PUR |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571725181 |
| Weight | 0.018000 |
| Zolltarifnummer | 84879090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
