ISO 15552-loop strap swivel fastening 50 mm, Burnished steel
Datasheet (PDF)
Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
In service the swivel eye mounting holds the cylinder and carries its forces into the machine frame. The decisive figure is a piston diameter of 50 mm. Dimensions 170 x 65 x 32 mm, made of burnished steel.

Swivel eye mounting ISO 15552, for piston diameter 50 mm, burnished steel

FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€41.84
Item FL-438904
Manufacturer no. TG 50 ST
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.TG 50 ST
EAN4050571872991
Customs tariff number73269098
ConditionNew
Add to Wish List Add to Compare
Artikel
FL-438904

This swivel eye mounting holds the cylinder and carries its forces into the machine frame. The stated material is burnished steel. The article is listed with a piston diameter of 50 mm.

Benefits

  • Designed for cylinders with a 50 mm piston diameter to ISO 15552.
  • Interface dimensions to ISO 15552 allow a replacement without changing the machine.
  • Material burnished steel for size 50 mm.
  • Dimension L comes to 170 mm for size 50 mm.
  • Dimension B comes to 32 mm for size 50 mm.

Technical data

Materialburnished steel
For piston diameter [mm]50
Dimension B [mm]32
Dimension D [mm]12
Dimension F [mm]27
Dimension L [mm]170
Dimension M [mm]65
Dimension N [mm]46.5
Scope of delivery1 swivel mounting incl. 4 fixing screws

Applications

In handling and clamping equipment the swivel eye mounting transfers the forces of the 50 mm cylinder into the frame.

Standards and conformity

The main dimensions follow ISO 15552 and therefore suit any cylinder of this size.

More Information
Norm ISO 15552
Hersteller-Nr TG 50 ST
Manufacturer Fluidics equipment
EAN 4050571872991
Weight 0.400000
Zolltarifnummer 73269098
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Original product
Artikelzustand New
Position sensing No
