Swivel head, male thread M 6, Stainless steel
Datasheet (PDF)
Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
The rod end links the piston rod to the load so that it can pivot. The underlying rating is the piston rod thread M 6. 6 x 46 x 36 mm in stainless steel.

Rod end, for piston rod thread M 6, stainless steel, dimension D 6 mm

FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€27.61
Item FL-045695
Manufacturer no. SGSA M6 ES
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.SGSA M6 ES
EAN4050571625467
Customs tariff number73269098
ConditionNew
Add to Wish List Add to Compare
Artikel
FL-045695

Once installed, the rod end links the piston rod to the load so that it can pivot. It is produced from stainless steel. The data give 6 mm for dimension D, 46 mm for dimension L and 36 mm for dimension H.

Benefits

  • Fits the piston rod thread M 6.
  • Material stainless steel for piston rod thread M 6.
  • Dimension D comes to 6 mm.
  • Dimension L comes to 46 mm.
  • Dimension C comes to 6.75 mm.

Technical data

Materialstainless steel
For piston rod thread AM 6
Dimension B [mm]9
Dimension C [mm]6.75
Dimension D [mm]6
Dimension D2 [mm]20
Dimension H [mm]36
Dimension L [mm]46
Dimension GL [mm]21

Applications

In feed and clamping equipment the rod end sits on thread M 6.

More Information
Hersteller-Nr SGSA M6 ES
Manufacturer Fluidics equipment
EAN 4050571625467
Weight 0.020000
Zolltarifnummer 73269098
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Original product
Artikelzustand New
Position sensing No
