Swivel head, male thread M 20, Stainless steel
Datasheet (PDF)
Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
This rod end links the piston rod to the load so that it can pivot. What counts here is the piston rod thread M 20. Material stainless steel, size 20 x 103 x 78 mm.

Rod end, for piston rod thread M 20, stainless steel, dimension D 20 mm

FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€104.48 €87.80
Item FL-571906
Manufacturer no. SGSA M20 ES
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.SGSA M20 ES
EAN4050571898878
Customs tariff number73269098
ConditionNew
Add to Wish List Add to Compare
Artikel
FL-571906
Frequently Bought Together

The rod end links the piston rod to the load so that it can pivot. This version is listed with 20 mm for dimension D, 103 mm for dimension L and 78 mm for dimension H. Its rating is the piston rod thread M 20.

Benefits

  • Fits the piston rod thread M 20.
  • Material stainless steel for piston rod thread M 20.
  • Dimension D comes to 20 mm.
  • Dimension L comes to 103 mm.
  • Dimension C comes to 19.00 mm.

Technical data

Materialstainless steel
For piston rod thread AM 20
Dimension B [mm]25
Dimension C [mm]19.00
Dimension D [mm]20
Dimension D2 [mm]50
Dimension H [mm]78
Dimension L [mm]103
Dimension GL [mm]45

Applications

In feed and clamping equipment the rod end sits on thread M 20.

More Information
Hersteller-Nr SGSA M20 ES
Manufacturer Fluidics equipment
EAN 4050571898878
Weight 0.360000
Zolltarifnummer 73269098
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Original product
Artikelzustand New
Position sensing No
