Swivel head, male thread M 12, Zinc plated steel
Datasheet (PDF)
Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
This rod end links the piston rod to the load so that it can pivot. What counts here is the piston rod thread M 12. Material zinc-plated steel, size 12 x 70 x 54 mm.

Rod end, for piston rod thread M 12, zinc-plated steel, dimension D 12 mm, dimension L 70 mm

FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€32.17 €27.03
Item FL-043842
Manufacturer no. SGSA M12
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.SGSA M12
EAN4050571625399
Customs tariff number73269098
ConditionNew
Add to Wish List Add to Compare
Artikel
FL-043842
Frequently Bought Together

Once installed, the rod end links the piston rod to the load so that it can pivot. It is supplied with 12 mm for dimension D, 70 mm for dimension L and 54 mm for dimension H. The article is made of zinc-plated steel.

Benefits

  • Fits the piston rod thread M 12.
  • Material zinc-plated steel for piston rod thread M 12.
  • Dimension D comes to 12 mm.
  • Dimension L comes to 70 mm.
  • Dimension C comes to 12.00 mm.

Technical data

Materialzinc-plated steel
For piston rod thread AM 12
Dimension B [mm]16
Dimension C [mm]12.00
Dimension D [mm]12
Dimension D2 [mm]32
Dimension H [mm]54
Dimension L [mm]70
Dimension GL [mm]32

Applications

In feed and clamping equipment the rod end sits on thread M 12.

More Information
Hersteller-Nr SGSA M12
Manufacturer Fluidics equipment
EAN 4050571625399
Weight 0.090000
Zolltarifnummer 73269098
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Original product
Artikelzustand New
Position sensing No
