Double-acting short-stroke cylinder, bore 16 mm, stroke 15 mm, without magnetic piston, M 5 - Fluidics equipment

Fluidics equipment ✓ Original product Brand new

With only 15 mm stroke this double-acting short-stroke cylinder with 16 mm bore delivers a calculated 121 N push force at 6 bar. Version without magnetic piston for tasks without position sensing. Stainless steel 1.4305 piston rod, operating pressure max. 10 bar.

Net
€50.05
excl. VAT
Item FL-273447
Manufacturer no. ND 16/15
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The double-acting short-stroke cylinder with 16 mm piston delivers a calculated 121 N push force at 6 bar. The 15 mm stroke keeps the overall length short, the port is M 5.

Key benefits

  • Pneumatic force in both directions, 121 N push force at 6 bar (calculated)
  • Piston rod thread M 4, rod made of 1.4305
  • Temperature range -20 to +80 °C with NBR seals
  • Operating pressure up to 10 bar, M 5 compressed air port

Dimensions

The dimension letters refer to the dimensional drawing of the series.

Dimension A34.0 mm
Dimension B30 mm
Dimension D8 mm
Dimension F4.7 mm
Dimension G7.5 mm
Dimension H19.0 mm
Dimension I18 mm
Dimension J8.0 mm
Dimension L27.0 mm
Dimension M12.0 mm
Dimension N20.0 mm
Dimension O10.0 mm
Dimension Q4.6 mm
Dimension R3.5 mm
Dimension S32.0 mm
Dimension T8 mm
Dimension V6 mm
Dimension W4.5 mm

Applications

Typical tasks are clamping and positioning workpieces, stoppers on conveyor lines or short pressing operations with 15 mm stroke. The force figure for the 16 mm bore is theoretical, friction losses come on top.

Technical data

Typeshort-stroke cylinder
Functiondouble-acting
Bore16 mm
Stroke15 mm
Versionwithout magnetic piston
Piston rod thread C1M 4
Compressed air port PM 5
Operating pressuremax. 10 bar
Temperature range-20 to +80 °C
Head and base plateanodised aluminium / brass
Cylinder tubeanodised aluminium
Piston rod1.4305
SealNBR
Cylinder switch typeG
Piston area (calculated)2.0 cm²
Push force at 6 bar (calculated)121 N
Push force at 10 bar (calculated)201 N
Weight85 g
Customs tariff number84799070
ManufacturerFluidics equipment
Hersteller-NrND 16/15
EAN4050571522858
Zolltarifnummer84799070
GPSR HerstellerdatenA1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Ausführungohne Magnetkolben
BauformKurzhubzylinder
Piston Ø [mm]16
Stroke [mm]15
Seal materialNBR
Housing materialAluminium, anodised
MediumCompressed air
Betriebsdruck max [bar]10
Pneumatic connectionM5
Temperaturbereich-20-80 °C
Temperature (max.)80

Downloads

Questions about this item

Any other question?

Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
