Rodless short cylinder Ø 63 mm, stroke 2000 mm, G 3/8, short design, magnetic piston - Fluidics equipment

Short-design rodless cylinder Ø 63 mm with 2000 mm stroke. Instead of a piston rod, force is passed through the tube slot directly to the yoke.

Benefits

• Up to 42% shorter than the standard series, space-saving even compared with short-stroke cylinders with piston rod
• Adjustable cushioning at both ends with 49 mm cushioning length
• Compressed air port G 3/8 on both sides, convertible to one side or underneath by moving the sealing plugs
• Magnetic piston for end-position sensing with cylinder switches
• Tube, cylinder heads and driver in anodised aluminium, stainless steel cover band, NBR/PUR seals

Applications

Installation: any position is possible, preferably with the yoke facing down to avoid contamination. Compressed air is supplied via G 3/8. Compared with the standard series of the same 63 mm piston diameter, this version is up to 42% shorter.
