Connecting plate for rodless cylinders Ø 40 mm / Ø 40 mm, link to a 2-axis system - Fluidics equipment
Connecting plate for building a 2-axis system from two rodless guide cylinders Ø 40 mm and Ø 40 mm. Please order the guide cylinders separately.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The connecting plate for 40 mm / 40 mm piston diameter joins two rodless guide cylinders into a 2-axis system. The guide cylinders are ordered separately.
Benefits
- Two axes with 40 mm and 40 mm piston diameter coupled by one part
- Dimensions A1 150 mm, FE1 220 mm and C 168 mm as per dimension table
- Guide cylinders can be ordered separately with the stroke required
Applications
For building a 2-axis system from two rodless guide cylinders with 40 mm piston diameter.
Technical data
| Feature | Value |
|---|---|
| Product type | Connecting plate |
| Suitable for | rodless guide cylinders |
| Piston diameter cylinder 1 | 40 mm |
| Piston diameter cylinder 2 | 40 mm |
| Dimension A1 | 150 mm |
| Dimension A2 | 150 mm |
| Dimension C | 168 mm |
| Dimension D | 105 mm |
| Dimension FE1 | 220 mm |
| Dimension FE2 | 220 mm |
| Dimension S | 10 mm |
| Weight | 1.1 kg |
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | LZ 40/40 KT |
| EAN | 4050571469665 |
| Zolltarifnummer | 84129080 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Piston Ø [mm] | 40 |
