Kupplungsstecker (NW7,2) 4mm Schlauch, Messing

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Coupling plug NW 7.2, hose connection 4 mm, brass - Fluidics equipment

Name: Coupling plug NW 7.2, hose connection 4 mm, brass - Fluidics equipment
Brand: Fluidics equipment
SKU: FL-008028
Price: 2.20 EUR
Availability: InStock

Fluidics equipment ✓ Original product Brand new

For NW 7.2 workshop couplings: coupling plug with hose connection 4 mm, rated for -0.95 to 35 bar. Body in brass, temperature range -20 to +100 °C.

Net

€2.20

excl. VAT

Item FL-008028

Manufacturer no. KSS 4 NW7

Question about this item

Datasheet (PDF) 2 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The coupling plug NW 7.2 with hose connection 4 mm couples compressed air lines without tools and separates them in one move. The version with hose 4 mm is rated for -0.95 to 35 bar.

Benefits

Operating pressure -0.95 to 35 bar, also for vacuum down to -0.95 bar
Flow rate up to 2100 l/min, depending on the coupling socket
Body in brass
Temperature range -20 to +100 °C
Compatible with Rectus 25/26/1600/1625, CEJN 320, Festo KD4/KS4 and other NW 7.2 systems

Technical details

Where it is used

The coupling plug is intended for tool connections at workstations and assembly lines. For installation, it connects to the hose line via its 4 mm hose connection.

Technical data

Feature	Value
Product type	Coupling plug
Coupling profile	NW 7.2
Connection	Hose connection 4 mm
Material	Brass
Operating pressure	-0.95 to 35 bar
Temperature range	-20 to +100 °C
Flow rate	1100 l/min with standard socket, 1850 l/min with ball locking, 2100 l/min with ball locking and plastic sleeve
Compatible with	Rectus (25, 26, 1600, 1625), TEMA (1600), CEJN (320), JWL (520, 530, 560), Legris (25, 26), Parker (PE, PEF), Prevost (E...07), Festo (KD4, KS4, NPHS), IMI-Norgren (238), Aventics (CP1-NW 7 / 7,8)
Weight	12 g
Manufacturer	Fluidics equipment
Hersteller-Nr	KSS 4 NW7
EAN	4050571153731
Zolltarifnummer	84812090
GPSR Herstellerdaten	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikelzustand	New
Artikel-Authentizität	Original product
For hose ID [mm]	4
Nominal size DN [mm]	7,2
Betriebsdruck max [bar]	35
Temperaturbereich	-20-100 °C
Temperature (max.)	100
