Bulkhead coupling socket NW 7.2, hose connection 8 mm (5/16 inch), brass, for BA plugs - Fluidics equipment

Fast coupling, safe separation: the bulkhead coupling socket NW 7.2 with hose connection 8 mm (5/16 inch) works at -0.95 to 35 bar and reaches a flow rate of 800 l/min.

Key benefits

• Operating pressure -0.95 to 35 bar, also for vacuum down to -0.95 bar
• Flow rate 800 l/min with BA counterpart
• Body in brass, NBR seal
• Temperature range -20 to +100 °C
• Counterpart for NW 7.2 BA plugs with double shut-off

Specifications

Where it is used

In the NW 7.2 coupling profile, the bulkhead coupling socket is intended for tool connections at workstations and assembly lines. It connects to the hose line via its 8 mm hose connection.

Designed as the counterpart to the NW 7.2 BA plugs with double shut-off.
