Coupling socket NW 7.2, G 1/4 male thread, brass - Fluidics equipment

Fast coupling, safe separation: the coupling socket NW 7.2 with G 1/4 male thread works at -0.95 to 35 bar and reaches a flow rate of 1100 l/min.

Key benefits

• Operating pressure -0.95 to 35 bar, also for vacuum down to -0.95 bar
• Flow rate 1100 l/min with standard coupling plug
• Body in brass, NBR seal
• Temperature range -20 to +100 °C
• Compatible with Rectus 25/26/1600/1625, CEJN 320, Festo KD4/KS4 and other NW 7.2 systems

Specifications

Applications

The coupling socket is screwed directly into the device, manifold or wall outlet via its G 1/4 male thread. Field of use: tool connections at workstations and assembly lines.
